Double-sided Printed Circuit Board

Name: Double-sided Printed Circuit Board
Brand: Sinofast
Availability: InStock

FOB Price

USD $0.5 - $2.5 / Piece

1 Piece(Min.Order)

Supply Ability 10000 Square Meter / Square Meters per Month
Port Shen Zhen
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Guangdong, China	Brand Name:	Sinofast	Model Number:	Sinofast 051072
Number of Layers:	Other, 1-28 layer	Base Material:	FR4	Copper Thickness:	1 oz
Board Thickness:	0.20mm	Min. Hole Size:	10mil	Min. Line Width:	4mil
Min. Line Spacing:	4mil	Surface Finishing:	HASL

Product Description

My Skype ID:Fannieyang9898

Telephone: 13244796034

PCB Engineer Skype:peterlee8388

For PCB engineer question welcome to direct add our engineer Skype to talk

Company Information

Welcome to Sinofast

ShenZhen SinoFast Electronics co.,Ltd. was established in April,2005,After years'efforts, the company has expanded rapidly and kept Introducing new production equipments.We have also trained a professional team and perfected the quality management system ranging. the manufacture ability of our company is expanded rapidly. The annual output of double-sided and multi-layer PCB exceeds 100,000 s

work step:

Certification

1.We have the comprehensive quality control system.

2.Reasonable price

3.Quick turn delivery time from 24hours.

4.Certification(ISO/UL/RoHS).

5.11 years experience in exporting service.

6.We have no MOQ.

7.Product in high quality,Strict through theAOI(Automated Optical Inspection),

QA/QC,fly porbe ,E-testing.

_{Product Technology:}

		High precision prototype	PCB bulk production
Max Layers		1-28 layers	1-14 layers
MIN Line width(mil)		3mil	4mil
MIN Line space(mil)		3mil	4mil
Min via (mechanical drilling)	Board thickness≤1.2mm	0.15mm	0.2mm
	Board thickness≤2.5mm	0.2mm	0.3mm
	Board thickness>2.5mm	Aspect Ration≤13:1	Aspect Ration≤13:1
Aspect Ration		Aspect Ration≤13:1	Aspect Ration≤13:1
Board thickness	MAX	8mm	7mm
Board thickness	MIN	2 layers:0.2mm;4 layers:0.35mm;6 layers:0.55mm;8 layers:0.7mm;10 layers:0.9mm	2 layers:0.2mm;4 layers:0.4mm;6 layers:0.6mm;8layers:0.8mm
MAX Board size		*6101200mm**	*6101200mm**
Max copper thickness		0.5-6oz	0.5-6oz
Immersion Gold/ Gold Plated Thickness		Immersion Gold:Au,1—8u” Gold finger:Au,1—150u” Gold Plated:Au,1—150u” Nickel Plated :50—500u”
Hole copper thick		25um 1mil	25um 1mil
Tolerance	Board thickness	Board thickness≤1.0mm:+/-0.1mm 1.0mm<Board thickness≤2.0mm:+/-10% Board thickness>2.0mm:+/-8%	Board thickness≤1.0mm:+/-0.1mm 1.0mm<Board thickness≤2.0mm:+/-10% Board thickness>2.0mm:+/-8%
	Outline Tolerance	≤100mm:+/-0.1mm 100< ≤300mm:+/-0.15mm >300mm:+/-0.2mm	≤100mm:+/-0.13mm 100< ≤300mm:+/-0.15mm >300mm:+/-0.2mm
	Impedance	±10%	±10%
MIN Solder mask bridge		0.08mm	0.10mm
Plugging Vias capability		0.25mm--0.60mm	0.70mm--1Description
