Home > Products > Ferrite magnet > shanghai strong magnets Ceramic Magnet/ferrite core, magnet generator ,ceramic magnet,permanent magnet generators for sale,
shanghai strong magnets Ceramic Magnet/ferrite core, magnet generator ,ceramic magnet,permanent magnet generators for sale,
- 100000 Piece / Pieces per Month
- ahanghai
- Credit Card
Product Details
| Place of Origin: | Shanghai, China | Brand Name: | QC-Strong Magnets | Model Number: | as customer request, Y30,Y35H-1,Y35H-2,Y35H-3,Y35H-4H,Y38B,Y38H,Y40E,Y40B,Y45E,Y45B |
| Type: | Permanent | Composite: | Ferrite Magnet | Shape: | Other, as customer request |
| Application: | Industrial Magnet |
Product Description
Ferrite magnets
Applications
Widely used in many fields, such as Dc motors, Louderspeaks, Magnetic Separators, Automotive Sensors, Educations, etc.
Buyer Guide
Grade, shape & size, tolerance, coating requirement, magnetize direction, quantity are necessary details for a good quotation. Please send us drawings to make things clear if the magnet would be particularly customized.
Trading Conditions
1. Sample: We can provide some samples to test.
2. Delivery date: Around 7~20 days after receipt the 30% payment in advance.
3. Shipment terms: there are two shipping methods, one is by sea, and another one is by express, including DHL, UPS, FedEx, TNT and so on.
4. Packing methods: demagnetize packing box (for Air and Express) and normal packing box for sea
Specifications:
Grade | Enterprise standard | QC Y30 | QC Y35H-1 | QC Y35H-2 | QC Y35H-3 | QC Y35H-4H |
MMPA |
| C8 | C8D | C8B |
| |
TDK |
| FB4B |
| FB4D | FB4G | |
Br | Type | 395(3950) | 405(4050) | 400(4000) | 415(4150) | 380(3800) |
min | 385(3850) | 395(3950) | 390(3900) | 405(4050) | 370(3700) | |
Hcb | Type | 200(2500) | 255(3200) | 279(3500) | 235(2950) | 286(3600) |
min | 176(2200) | 251(3150) | 236(3300) | 223(2800) | 270(3400) | |
Hcj | Type | 205(2570) | 263(3300) | 287(3600) | 243(3050) | 342(4300) |
min | 184(2300) | 255(3200) | 275(3450) | 231(2900) | 326(4100) | |
(BH)max | Type | 29.0(3.7) | 31.2(3.9) | 30.4(3.87) | 32.8(4.1) | 27.2(3.4) |
min | 27.5(3.45) | 29.6(3.7) | 28.8(3.6) | 30.2(3.8) | 25.6(3.2) |
Grade | Enterprise standard | QC Y38B | QC Y38H | QC Y40E | QC Y40B | QCY45E | QCY45B |
MMPA |
| C12 | C9 |
|
|
| |
TDK | FB5B | FB5H | FB6E | FB6B | FB9H | FB6N | |
Br | Type | 420(4200) | 405(4050) | 380(3800) | 420(4200) | 430(4300) | 440(4400) |
min | 410(4100) | 395(3950) | 370(3700) | 410(4100) | 420(4200) | 430(4300) | |
Hcb | Type | 263(3300) | 298(3750) | 290(3650) | 302(3800) | 330(4150) | 259(3250) |
min | 251(3150) | 287(3600) | 279(3500) | 290(3650) | 318(4000) | 247(3100) | |
Hcj | Type | 267(3350) | 322(4050) | 398(5000) | 318(4000) | 398(5000) | 263(3300) |
min | 255(3200) | 311(3900) | 382(4800) | 307(3850) | 386(4850) | 251(3150) | |
(BH)max | Type | 33.4(4.2) | 31.1(3.9) | 27.5(3.4) | 33.5(4.2) | 35.0(4.4) | 36.7(4.6) |
min | 31.8(4.0) | 29.5(3.7) | 25.6(3.2) | 32.6(4.0) | 33.5(4.2) | 35.1(4.4) |
View More Pictures:
View the Factory Pictures:
Quality Assurance
To ensure the highest quality, R&D center and quality control center are founded. All of our products are manufactured Certificated CE & ISO9001:2008 quality standards.
Welcome to contact us if any help we can do for magnet requirement!
Contact Us
- Shanghai Strong Magnets Industrial And Commercial Company Ltd.
- Contact namenorman liu Chat Now
- Phone0086-021-56812690
- AddressRm. 505-506, Bldg. 12, Lane 858
-
