USB flash disk/Key Chain/Pen Laser Engraving Equipment

Wooden Case Package

Specifications

Laser Engraving Equipment
1.high speed galvo system
2.permanent marks
3.high Resolution
4.engrave logo,Icons,symbols,fonts

USB flash disk/Key Chain/Pen Laser Engraving Equipment

Laser engraving is the practice of using lasers to engrave, etch, or mark an object. Using a beam of light as a tool, engraving by laser produces a non-contact mark which results in less wear and tear on tooling and associated costs. There is also less chance for product damage and/or deformation. There are also no consumables and no problems disposing of toxic by-products.

Laser engraving produces a mark that is crisp, clean and permanent. Lasers are also faster than many conventional methods of product imprinting, providing greater versatility in material choices. Also, the same machine can cut through thin materials as well as engrave on them.

High precision markings are achievable on almost any type of material including gold, platinum, silver, titanium, tungsten, stainless steel, and aluminum, as well as a wide variety of plastics. Hallmarks, trademarks, stone weights, personalized text, serial numbers, corporate logos, and digital images, or any individual process data, can be produced with laser marking.

Our machine have the capability of putting a permanent laser mark on the inner surface of rings. It can mark any font or custom logo required by our customer.



Advantages over other methods of marking:

• Speed (cost effective compared to other methods of marking or identification)
• Accuracy
• Quality
• Repeatability
• Non-contact (curved surfaces can be accommodated)
• Barcodes and other 2-D codes
• Variable information (i.e. serial numbers)
• Flexibility (changes to a mark can easily be made)
• Permanence
• High Resolution
• Marking/Engraving Logos, Icons, Symbols and Special Fonts

Machine Specifications:

1. Imported fiber laser generator and high-speed galvanometer scanning system. Good beam quality, long working life (100,000 hours). Stable performance and maintenance-free.
2. With the features of High speed, high precision and high efficiency.
3. Precision, fine and permanent marks. Easy to use.
4. This model can achieve automatic arrangement and modification of text, logo, symbols ,images, graphics, bar code, two dimensional barcode, serial number automatically increasing, etc.
5. With a wide range of application.

[In appearance, there are integrated model and detached model for choice.]



Application Field:

This model can permanently mark a wide range of materials such as ordinary metals and alloys (steel, stainless steel, iron, copper, brass, aluminum, magnesium, zinc, etc.), rare metals and alloys (gold, silver, titanium, etc.), metal oxides, plastic, ABS material (electrical appliances shell, daily necessities), ink (translucent keypads, printed products), epoxy resin (electronic components, packaging, insulation layer), electroplating materials, coating materials, spraying materials, serial numbers and barcode marking, electric parts, mobile phone keypad, cell phone covers, surgical instruments, hardware metals, watch covers, rubber, ceramic, etc.



Technical Parameter:

Model No.	GDBGX-30
Laser generator	Fiber Laser
Laser power	20W
Standard marking area	70mm×70mm
Optional marking areas	35mm×35mm, 110mm×110mm, 130mm×130mm, 175mm×175mm
Working table	Manuel up and down aluminium alloy working table
Marking speed	0-7000mm/s
Cooling system	Air cooling
Control system	Digital offline control
Galvo positioning accuracy	±0.01mm
Power supply	AC220V ± 5% / 50/60Hz
Format support	AI, BMP, PLT, DXF, DST, etc.
Optional	Rotary device for cylinder marking Auto focus for different thickness objects marking 10W, 30W, 50W Fiber lasers



Laser Engraving/Marking Samples Gallery:
