Home > Products > LED Panel Light > LED 600X600 Ceiling Panel Light IR&RF&DALI LED Suspended Acrylic

LED 600X600 Ceiling Panel Light IR&RF&DALI LED Suspended Acrylic

FOB Price

USD $50 - $150 / Piece

5 Pieces(Min.Order)

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

LED Light Source:	SMD	Warranty(Years):	2	Input Voltage(V):	AC85-265V or DC12V
Lamp Power(W):	55	Lamp Luminous Flux(lm):	4400-4950	Lamp Luminous Efficiency(lm/w):	80
Color Temperature(CCT):	Other, Pure White:5500-6000K,Warm White:3000-3500K;Daylight:4000-4500K	Working Temperature(℃):	-30, +60	Working Lifetime(Hour):	50000
Lamp Body Material:	Aluminum	IP Rating:	Other, IP60	Certification:	CE, EMC, LVD, CE
Place of Origin:	Guangdong, China	Brand Name:	SEMLIGHT	Model Number:	SEM-P55-02

LED 600X600 Ceiling Panel Light IR&RF&DALI LED Suspended Acrylic

300x300 300x600 300x1200 600x600 600x1200 Used for kitchen, toilet, etc wherer have lampblack and water vapor. And other place where need.

Parameter:

Product	SEM-P15-01	SEM-P15-02	SEM-P30-01	SEM-P30-02	SEM-P30-03	SEM-P55-01
LED Parameter Specifications
Power	15W	15W	30W	30W	30W	55W
Luminous efficiency	80-90LM/W	80-90LM/W	80-90LM/W	80-90LM/W	80-90LM/W	80-90LM/W
Luminous flux	1200-1350LM	1200-1350LM	2400-2700LM	2400-2700LM	2400-2700LM	4400-4950LM
Emitting Color	RGB
	White	Warm white CT(3000-3500K)
		Daylight CT(4000-4500K)
		Pure white CT(5500-6000K)
		Cool white CT(6000-6500K)
LED chip	Bridgelux, Epistar
LED Type	SMD3528
LED quantity	186PCS	186PCS	372PCS	372PCS	372PCS	756PCS
Power source parameters
Input voltage	AC85-265V
Frequency Range	50/60HZ
Dimmable	Dimmable or nondimmable
Power Factor	>0.94
Power Effiency	>86%
Certificate	CE,RoHS,IEC
Technical parameters
LED consumption	12.9W	12.9W	25.8W	25.8W	25.8W	47.3W
System consumption	2.1W	2.1W	4.2W	4.2W	4.2W	7.7W
Dimension(mm)	30030012.3	30060012.3	30060012.3	300120012.3	60060012.	300120012.3
Beam Angle	120°
Material	Aluminum
IP Grade	IP54
Working Life Span	>50000hours
Color Rendering Index	>80
Working Temperature	-40degree——+50degree
Packaging information
Net Weight	2.05kgs/pc	3.12kgs/pc	3.12kgs/pc	6.79 kgs/pc	9.83 kgs/pc	6.79 kgs/pc
Gross Weight	2.38kgs/pc	3.5kgs/pc	3.5kgs/pc	7.00kgs/pc	10.5 kgs/pc	7.00kgs/pc
Box Size	504444CM 20PCS/CTN	504474CM 20PCS/CTN	504474CM 20PCS/CTN	4013080CM 1PC/CTN	727210CM 1PC/CTN	4013080CM 1PC/CTN

Please contact with us now for:
PDF data specification,Certificates and IES file.
