800TVL 4CH IR LED Security Long Range Wireless CCTV Camera System

Specifications

Long Range Wireless CCTV Camera System
1.Adopt PAL TV and video system
2.Monitor a wide and long-distance range



800TVL 4CH IR LED Security Long Range Wireless CCTV Camera System





Introductions:
If every public place is installed a useful monitoring device, it will reduces burglaries or other unpredictable accidents. This 1/4 CMOS 800TVL 24SMD LEDs Gun-shaped 4-channel DVR with IR-CUT is very helpful and necessary to reproduce the scene. Being a perfect security monitoring assistant, it is widely used in security management of some important locations, such as the living district, mall, hospital, bank, airport and highway toll. With latest technology, it could record the process effectively within the monitoring range in high definition. You could rest assured its excellent performance and great function. It will guarantee your safety.

Features:
1. Excellent material outer shell ensure fine heat emission
2. Gun-shaped appearance is attractive and striking
3. Adopt PAL TV and video system
4. Adopt the latest technology to produce stable and clear recording
5. Monitor a wide and long-distance range even a small angle
6. High definition in hue and image
7. With standard USB interface
8. Support IR remote control up to 15 meters
9. Support many mobile phone surveillance system, multi-language and remote control
10. 24SMD LEDs to provide you with clear and legible views of videos or pictures
11. Allow record, playback, backup, control and network operation at the same time

Specifications:
Camera:
1. TV System: PAL
2. Pixels: 500(H) x 582(V)
3. Image Device: 1/4" CMOS
4. Horizontal Definition: 800TVL
5. Minimum Illumination: 0 Lux (IR ON)
6. IR Distance: 15m
7. LED Quantity: 24pcs
8. Lens: 3.6mm
9. Power Adapter: DC 12V, 500mA
10. White Balance: Auto
11. Auto Gain Control: Auto
12. Electronic Shutter: 1/50 ~ 1/1000,000 sec
13. Color: Black
14. Dimensions: (5.91 x 1.97)" / (15 x 5)cm (L x Dia.)

DVR:
1. Video Compression: H.264
2. Video System: PAL
3. Operation System: Embedding Linux
4. Video Input / Output: 4 Channels BNC Input, 1 Channel BNC Output
5. Other Output: 1 x VGA, 1 x HDMI Output
6. Audio Input / Output: 1 Channel RCA Input, 1 Channel RCA Output
7. Network and Protocol: 1 x RJ45, 10/100M; Support TCP/IP, PPPCE, DCNS, DHCP, UPnP
8. Display Resolution: D1(704x576)
9. Recording Resolution: D1(704x576), HD1(704x240), CIF(352x240)
10. Recording Frame Rate: D1@100fps, HD1@100fps, CIF@100fps
11. Recording Backup: 1/4 Channels playback
12. Recording Mode: Manual, Timer, Motion Deteciton, Remote
13. Recording Backup: USB, Moved Hark Disk, USB Writer, Network
14. Network Transmission: 4 Channels Real-time Network Transmission with QCIF Resolution
15. Email Alarm: Send Pictures to the designated email
16. Multiplex Operation: Live, Display, Playback, Recording, Backup, Mobile phone Surveillance, Network Simultaneously
17. HDD: Support 1 STAT HDD, Capacity to 2TB
18. Mobile phone Surveillance: Support Windows, Symbian, iPhone, Blackberry, Android OS
19. Multi-Language: Support
20. PTZ Control: PELCO-D, PELCO-P
21. USB: 2 x USB 2.0
22. Remote Control: Support
23. Power Supply: DC 12V, 3A
24. Dimensions: (8.46 x 10.04 x 1.77)" / (21.5 x 25.5 x 4.5)cm (L x W x H)

Environmental:
1. Working Temperature: 0°C-+55°C
2. Working Humidity: 10%-90%
3. Total Weight: 3950 g / 139.33 oz

Package Includes:
1 x 4 Channel DVR
4 x Cameras
3 x 20m Connecting Cables
1 x Mouse
1 x Remote Control
2 x UK Standard Power Adapter
1 x CD Driver
1 x Power Cable
