Specifications
Movable Asphalt Mixing Plant Manufacturer20-100t/h
ISO9001,ISO14001
CE,Gost
Asphalt Mixing Plant Manufacturer 20 years
Movable Asphalt Mixing Plant Manufacturer
Zhengzhou Dayu Machinery Co.,Ltd is a professional construction machinery manufacturer for Movable Asphalt Mixing Plant Manufacturer over 20 years.
Dayu have three main groups of Asphalt Mixing Plant Manufacturer,
Movable Asphalt Mixing Plant Manufacturer
Small Asphalt Mixing Plant Manufacturer
Batch Asphalt Mixing Plant Manufacturer
The Components of Movable Asphalt Mixing Plant Manufacturer including Four Bin Feeder, Vibrating Screen System, Slinger Conveyor, Dryer Drum, Bitumen Tanks, Multicylone Exhaust, Load Out Conveyor, Mineral Filler, Control Cabin and Ldo Tank, which can working with good quality and high efficiency.
Main Parameters of Movable Asphalt Mixing Plant Manufacturer MDHB Series
| Model | Productivity(t/h) | Weighing Accuracy | Total Power(kW) | Coal Consumption(kg/t) | |
| Aggregate | Asphalt | ||||
| DHB-20 | 20 | ±1.5% | ±1% | 40 | 10 |
| DHB-40 | 40 | ±1.5% | ±1% | 75 | 10-13 |
| DHB-60 | 60 | ±1.5% | ±1% | 128 | 10-13 |
| DHB-80 | 80 | ±1.5% | ±1% | 165 | 10-13 |
| DHB-100 | 100 | ±1.5% | ±1% | 200 | 10-13 |
Main Structure of Movable Asphalt Mixing Plant DHB Series
1 Cold aggregate supply system (mobile)
2 Middle filter
3 Drying drum (mobile)
4 Asphalt supply system
5 Electric control system
Batch Asphalt Mixing Plant
Dayu LB series Batch Asphalt Mixing Plant mainly including burning system,drying drum,dust collecting system,mixing system,bitumen supply system,accurate measuring system,electric control system,asphalt storage system.
For the asphalt storage system: integrated storage bins and separated storage bins types.
For the dust collenting system: water dust and bag dust types.
For the burning system: oil burner,gas burner and coal burner types.
Output: 40-320 TPH.
| Type | Plant Capacity (standard conditions): | Mixer Capacity: | Consumption (standard conditions): | Measurement accuracy | |
| Fuel Oil | Fuel Coal | ||||
| LB500 | 40 t/h | 500 kg | 5.5-7 kg/t | 10kg/t | Aggregate: ±0.5% Powder: ±0.5% Asphalt: ±0.25% |
| LB700 | 56 t/h | 700 kg | 5.5-7 kg/t | 10kg/t | |
| LB800 | 64 t/h | 800 kg | 5.5-7 kg/t | 10kg/t | |
| LB1000 | 80 t/h | 1000 kg | 5.5-7 kg/t | 10kg/t | |
| LB1100 | 90 t/h | 1100 kg | 5.5-7 kg/t | 10kg/t | |
| LB1200 | 100 t/h | 1200 kg | 5.5-7 kg/t | 10kg/t | |
| LB1250 | 105 t/h | 1250 kg | 5.5-7 kg/t | 10kg/t | |
| LB1500 | 120 t/h | 1500 kg | 5.5-7 kg/t | 10kg/t | |
| LB1600 | 130 t/h | 1600 kg | 5.5-7 kg/t | 10kg/t | |
| LB2000 | 160 t/h | 2000 kg | 5.5-7 kg/t | 10kg/t | |
| LB2200 | 175 t/h | 2200 kg | 5.5-7 kg/t | 10kg/t | |
| LB2500 | 200 t/h | 2500 kg | 5.5-7 kg/t | 10kg/t | |
| LB3000 | 240 t/h | 3000 kg | 5.5-7 kg/t | 10kg/t | |
Warranty Period ;12 months since delivery the machine .
More information can be get by contact with Zhengzhou Dayu Machinery Co., Ltd
