Home > Products > Low alloy tool steel > DIN1.2510 tool steel
DIN1.2510 tool steel
- 30000 Ton / Tons per Month
- any port in China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Grade | cold work tool steel | Standard | AISI, DIN, GB, JIS | |
| Thickness | 12-60mm(rolled) | Width | 200-610mm | |
| Length | 2000mm-6000mm | Place of Origin | Hubei, China | |
| Brand Name | Boda | Model Number | din1.2510/O1/9CrWMn | |
| Application | tool steel bar | Technique | Hot Rolled | |
| Special Use | Mold Steel |
Product Description
Specifications
DIN1.2510 tool STEEL1 In stock
2 annealed + black
3 EAF/ERS hot rolled
4 ISO9001:2008 certificate
din 1.2510 tool steel
Steel grade: DIN1.2510 GB 9CrWMn AISI O1
1.Chemical Composition(%)
| Steel grade | C | Si | Mn | P | S | Cr | W | V |
| DIN1.2510 | 0.85-0.95 | ≤0.40 | 0.90-1.20 | ≤0.03 | ≤0.03 | 0.50-0.80 | 0.50-0.80 | - |
2. Available sizes :
Rolled flat bar Thickness 112-60mm width:200-610mm Rolled Round bar dia. 50-130mm
Forged flat bar Thickness:60-200mm width:100-800mm Forged round bar dia. 50-400mm
3 Annealed.hardness :197-241HBS
4 Properties
• Good wear resistance, and good hardenability
• Resistance to plastic deformation
5 Applications
It is universally used for manufacture of cutting tools, blanking and stamping dies, thread cutting tools, machine knives for the wood paper and metal working industries, broaches, measuring tools, etc.
Furnce material-melting-steel ingot-forging-forging billet-heating-rolling -slow cooling-collecting-annealing-finishing-inspection-package-warehousing
8. Delivery condition
Annealed + black/peeled/turned/grinding/polishing surface option, Ultrosonic test accord with SEP 1921-84 class c/c
