ME2 | |||
1. Powerful and first-class configurations Dual-core: adopts Qualcomm 8625 dual-core 1.2GHz processor.6000 times: key connectors passed 6000 times’ plug testing. 2. Large screen, ergonomic design 5.0 inches: 5.0 inches with Hi-Res.Ergonomic design: antibacterial shell and handhold structure. 3. Commercial level protection, longer product life It supports dual-band wifi, equipped with 5G wifi commonly used in medical system. 2D scan engine with high performance, scan faster. 4. Double batteries & long battery life Double batteries: special design provides continuous power supply for battery replacement. Long battery life: supports continuous work for at least 8 hours. | |||
Physical parameters | |||
Dimensions | 150mm H * 80mm W * 12mm D | ||
Weight | 260g (battery included) | ||
Operating Temp | -20°C~60° | ||
Storage Temp | -40°C~80° | ||
Humidity | 10%-90% RH non-condensing | ||
Drop Test | 1.0-meter drop protection | ||
IP grade | IP54 | ||
ESD protection | ±8KV contact discharge; ±15KV air discharge | ||
System Parameters | |||
CPU | Qualcomm MSM8625 dual-core 1.2GHz | ||
OS | Android 4.1 | ||
RAM/ROM | ROM 4GB eMMC; RAM 512MB DDR2; Support external micro SD card, 32 GB at most | ||
Display | 5.0 inch capacitive, multi touch; 480*800, IPS display | ||
Keypad | 3 touch keys (Android System key), 4 physical keys (include Power key, Scan key, Volume key) | ||
Battery | Lithium polymer battery, 3.7V, 3000mAh+110mAh | ||
Functional Configuration | |||
Bar Codes Scanning | 2D Motorola SE4500 | ||
Camera | Rear Camera 5M AF (support flashlight) | ||
Indicator Light | System indicator light; Scanning indicator light | ||
Audios | Built-in speaker, microphone, 3.55mm stereo headphone jack, vibrator | ||
Sensors | Gravity sensor | ||
Network Parameters | |||
WLAN | 802.11 b/g/n Built-in Antenna | ||
WPAN | BluetoothV4.0+EDR | ||
External Interface | |||
USB Interface | Micro USB2.0, support USB OTG | ||
Charger Jack | Micro USB2.0, 1A quick charger | ||
Power Supply Jack | Pogo Pin, 5V--500mA | ||
Communication | USB, RS232 | ||
Development Environment | |||
System Environment | Android 4.1/SP-UI | ||
Development Environment | SP-SDK | ||
Management Software | SP-PC management suite/MDM | ||
| Packaging Details: | Android handheld AIDC terminal with bar code scanner NFC ME2 Package 1*3000mAh+110mAh battery 1* USB cable 1* Earphone 1* Power adaptor 1* User Manual 1* Screwdriver |
|---|---|
| Delivery Detail: | 3-5 working days |
1.Perfect ODM/OEM service.
2.12 month warranty.
3.SDK support.
Touch screen and keypad Android barcode scanner
...
