paper core tube machine
Negotiable
/ Set
1 Set(Min.Order)
- 30 Set / Sets per Month
- tianjin
You May Like
-
UNI-4250 4 heads paper tube winding machine
-
UNI-4550 high speed big paper tube forming machine with 4 heads
-
UNI-1500B auto paper tube cutting machine
-
UNI-800A simple paper tube recutting machine with 5 blades
-
good quality paper tube curling machine
-
UNI-4350 paper core making machine with high quality
Product Details
| Condition: | New | Product Type: | Paper Core Machine | Processing Type: | Winding Machine |
| Place of Origin: | Hebei, China | Brand Name: | unipand | Model Number: | UNI-80B |
| Voltage: | 380V,3phase,4wire,50Hz | Power(W): | 18KW | Dimension(L*W*H): | 4500*2000*2000mm |
| Weight: | 3100kg | Certification: | CE | Warranty: | 1 year |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
UNI-4350 Paper Tube Making Machine with four head Main Specification and Equipment
Parameter
| tube diameter | 20-350mm | number of roller | 24plies |
| tube max thickness | 16mm | rewinding noses | 4noses |
| operator | 2-4 | productive speed | 3-15m/min |
| way of cutting | pneumatic | way of gluing(auto) | double sides |
| paper-shelf type | crisscross | way of tube down | withdraw |
| power of mainframe | 18KW | power input | 380V,3phase,4wire,50Hz |
Size (mm)
| mainframe(L*W*H) | 4500*2000*2000 | area space(L*W) | 16000*9000 |
| wheel hub diameter | 325 | wheel hub height | 400-600 |
| tread | 1100*1400 | total weight | 3100kg |
Driving System
| modle of main motor | 18KW Weihai | mainframe rotate speed | 1400r/min |
| hub max rotate speed | 50r/min | hub output torque | 2850N.m |
| reductor type | WPO155 | modle of driving chain | 16A*1 |
| wheel hub drive | 4wheel | cutting motor | A ball |
| glue pump | 1.5KW,gear pump | screw | China |
| slideway | 400mm,round slideway | bearing | Haerbin |
Control System
| PLC controller | Delta,DVP-24ES000R2 | edition of program | JS-A3.1 |
| inverter | 18KW,Anchuan | driving components | CHNT |
| signal components | Omron | pneumatic components | AIRTAC |
| angle setting motor | -- | cutting blade control device | pneumatic |
| way of fixing length | infrared | synchronism control cutting System | -- |
