Industrial Heating Exchanger: Evaporator

Name: Industrial Heating Exchanger: Evaporator
Brand: Frigeast
Availability: InStock

FOB Price

USD $1 - $100,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:

Jiangsu, China

Brand Name:

Frigeast

Model Number:

PC/PCE/PE

P series evaporator (also called air-cooler) is a cooling device for various sorts of cold rooms.

P series evaporator (also called air-cooler) is a cooling device for various sorts of cold rooms. P series evaporator includes PC,PCE and

PE air coolers used for different cold rooms respectively; which have the merits of compact structure

and light weight and they occupy no usable space. They can decrease the food

temperature stored in the cold room very fast and enhance the freshness of the stored food, comparing

with natural convection piping arrangement. P series evaporator can be assembled to compressed condensing

unit with different refrigerating capacity, fixed to cold rooms of various temperatures as a cooling device.

PCE type is suitable for cold rooms with a temperature of -18 °C, such as cold rooms for storing freezing meat and fish .
											model	Capacity (KW)Temp. -18°C T=7°C	Cooling area M2	Parameters of fans						defrosting
No. (Unit)	Dia. Of fan φmm	Volume (m3/h)	Pressure (Pa)	Voltage(V)	Power(W)	Power(W)	Voltage(V)							Parameters of fans						defrosting
No. (Unit)	Dia. Of fan φmm	Volume (m3/h)	Pressure (Pa)	Voltage(V)	Power(W)	Power(W)	Voltage(V)	PCE-3/15	3	15				1	φ330	2000	98	380/220	120	2700	220
PCE-4.4/22	4.4	22	2	φ330	2×2000	98	380	2×120	3600	220
PCE-5.2/26	5.2	26	2	φ330	2×2000	98	380	2×120	3900	220
PCE-6/30	6	30	2	φ330	2×2800	98	380	2×120	3900	220
PCE-8/40	8	40	2	φ400	2×3000	118	380	2×250	5400	220
PCE-12/60	12	60	2	φ500	2×6000	167	380	2×450	7800	220
PCE-16/80	16	80	2	φ500	2×6000	167	380	2×550	10200	220
PCE-20/100	20	100	3	φ500	3×6000	167	380	3×550	12600	220
PCE-24/120	24	120	4	φ500	4×6000	167	380	4×550	14400	220
PCE-28.2/140	28.2	140	4	φ500	4×6000	167	380	4×550	18000	220
PCE-32/160	32	160	3	φ600	3×10000	167	380	3×1100	21600	220
PCE-40/200	40	200	4	φ600	4×10000	200	380	4×1100	24300	220
PCE-50/250	50	250	5	φ600	5×10000	200	380	5×1100	29700	220
