2014 Top sale stable quality Portable ultrasonic spot welding machine for garment / plastic

Carton or according to customers' requirement

Specifications

1.Portable ultrasonic spot welding machine
2. 45~120 pcs/min
3. 80-150W
4. Ultrasonic welding
5. manual operation

2014 Top sale stable quality Portable ultrasonic spot welding machine  for garment / plastic



Application of Portable ultrasonic spot welding machine

1. Hot fix rhinestones onto apparel and textile , paper card , jeans ,leather .

2. Inlay the pointback rhinestones into wooden,plastic,acrylic products.

3. Spot welding fabric to fabric , such as ,  underwear

4. Welding the plastic to plastic



Main features of Portable ultrasonic spot welding machine



1.High-grade multifunctional ultrasonic series models, different from the

kind of electric iron plug type.

When in operation ,it will not  spoil material and scald operator's hands.

2.One piece rhinestone can be firmly hot fix on the material in 1 second.It is high efficient for mass production.

3.Simple to use, no need for glue or solder.Machine inside is equipped with

vacuum pump.It automatically adsorb rhinestones or sequins.

4.welding time can be timed or manual controlled.

5.Low Power consumption, strong effect , low noise, small volume.



Technical parameter of Portable ultrasonic spot welding machine

Model	AZSDZ01
Voltage	220V/50Hz 110V/60Hz
Output Frequency	28KHz
Power	80-150 W
Efficiency	45-120pcs/min
Dimension(L*W*H)	268*168*198mm
Machine weight	7kg





Manually ultrasonic spot welding machine with different welding head
