Breeder chain pan feeding system

                                          Breeder chain feeding system

                                                                                                (U-Best)

Breeder chain pan feeding system:

* Automatically control motor by feed sensor for delivering feed,it could meet the birds growing request.

* Each feed pan has feed at the same time,eliminates hunger stress,making growth more uniform and laying rate higher.

* Using a plastic disc on the chain frive feed in the feed tube in advance,reducing the damage of feed,closed transmission,reducing noise pollution.

* Soft chain connection,cyclic feeding,easy to install.

* Before putting into the breeder,one-time suspension installation,lifetime use,stocking density increased 30% than chain feed line.

Female breeder feed pan:

The main characteristics of the female breeder feed pan:

* 4 pans/3m,feed pan distance:750mm.

* Feed pan diameter:360mm.

* Material:PP---Polypropylene.

* Feeding capacity:average 12.5birds/pan.

* 16 grills width of 40-52mm divide into 11 files,suitable for all the different varieties and day-old broiler breeder feeding needs.

* Feed hole height of 70mm,80mm,90mm three files,when feed hole width be 52mm,height be 90mm,chicks can in and out freely.

* When height be 70mm,feed does not spill,save feed.

* Feed pan capacity:16 grades file,200-630g/pan,which can meet the demand of chicken feed in different stages.

* Full switch design,can switch each pan easily.

* Bottom of the pan is hanging pan bottom,taken down easily,when washing is not all removed,convenient and healthy when installed.

Male breeder feed pan:

Layout for breeder feeder pan system:

Breeder feeder pan system layout parameter:

Egg laying box system:

Range of application:Rearing laying hens,breeders.

Configuration:High quality hot galvanized plate,PVC pedal
