Ceramic Rasching Ring,industrial ceramic ring with 1", 1 1/2". 2"

FOB Price

USD $160 - $220 / Metric Ton

1 Metric Ton(Min.Order)

Supply Ability 1000 Metric Ton / Metric Tons per Month
Port Shenzhen Shanghai and any port in China
Payment Terms:T/T L/C D/P D/A Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Jiangxi, China	Type:	Ceramic Rings	Application:	Industrial Ceramic
Material:	Alumina Ceramic	Model Number:	Raschig ring	Brand Name:	ZY

Product Description

Specifications

1)20 years professional manufacture
2)industrial ceramic ring
3)Ontime delivery
4)One-stop service
5)ISO9001:2000

Ceramic Rasching Ring, industrial ceramic ring
is a traditional packing with simple shape and the outside diameter is equal to the height. The large size of the Rasching ring (above 100mm ) generally use the entire masonry filling, the size below 80mm generally use the random packing.

Features/function:

1)High free volume, large void space;

2)low pressure drop;

3)Top mass transfer performance

4)High floating point;

5)Excellent corrosion and heat resistance

Material:

Ceramic

Application:

Used in chemical industry, Alkali industry,protection of environmental, petroleum industry ,coal gas industry,etc .It’s available for the distillation and absorption of a liquid and gas, atmospheric and vacuum distillation unit, crude distillation unit, desulphurization system, gas liquid separator/separate of the gas and liquid etc.

Technical data of the Ceramic Rasching Ring:

Specification (mm)	Diameter* Height* Thickness (mm)	Surface area (m²/m³)	Void space (%)	Number per m³	Bulk density (kg/m³)	Packing factor (m-1)
6	662	789	73	3110000	737	2030
10	10102	440	70	720000	700	1280
15	15152	330	70	250000	690	960
16	16162	305	73	192500	730	784
25	25252.5	190	78	49000	505	400
40	40405	136	75	12700	577	305
50	50505	93	81	6000	457	177
80	80809.5	90	68	1910	714	234
100	10010010	70	70	1000	700	172
150	15015015	50	68	295	790	142

Ceramic Raschig Ring Sample Photo:

Ceramic Random Packing Production:
