Sinking Fish Feed Making Machine

Specifications

Sinking Fish Feed Making Machine
1.For fish, dog, poultry
2.Pellet size 1.2~16mm
3.Floating

Sinking Fish Feed Making Machine



Fish feed pellet drying machine is widely used for producing grains into high-grade aquatic feed pellets for fish, catfish, shrimps, crab etc.
The puffing fish feed pellets can float on the water surface without dissolution for over 12 hours. According to your requirements and production scale, floating fish feed machine can be classified into dry type machine and wet type machine.



Sinking Fish Feed Making Machine--Application and Features:

1.According to different requirements, variety shapes of high-grade feed pellets for fish, shrimps .etc can be produced.

2.The finished pellets can keep floating for 3-15 hours without pollution to water.

3.The floating time can be controlled by the puffing degree adjustment.

4.Floating fish feed machine can make pellet from dia.1.0mm-20mm just by changing the mold.

5.Electric heating device is adopted which can improve the feed expansion rate and pellets floating time.

6.High temperature and high pressure cooking process can kill the salmonellosis and bacterial infections and also makes the pellets easily to digest.

7.The cutting device can be adjusted to make pellets of different length.

8.The wet type machine needs a boiler to make steam which can conduct steam to the conditioner and ripen the raw material in advance.



Sinking Fish Feed Making Machine--Dry type:

Model	Capacity  t/h	Main power   kw	Feeding Power  kw	Screw diameter  mm	Cutting Power  kw
JCYG50	0.06-0.08	0.4	0.4	Φ50	0.4
JCYG60	0.12-0.15	15	0.4	φ60	0.4
JCYG70	0.18-0.2	18.5	0.4	φ70	0.4
JCYG80	0.2-0.25	22	0.4	φ80	1.1
JCYG90	0.32-0.35	37	1.1	φ90	1.5
JCYG120	0.5-0.6	55	1.1	φ120	2.2
JCYG135	0.7-0.8	75	1.1	φ133	2.2
JCYG160	1-1.2	90	1.5	φ155	2.2
JCYG200	1.8-2.0	132	1.5	φ195	3.0



Sinking Fish Feed Making Machine--Wet Type:

Model	Capacity   t/h	Main power   kw	Feeding Power  kw	Screw diameter  mm	Cutting Power  kw	Conditioner Power  kw
JCYS60	0.18-0.2	15	0.75	60	0.75	0.37
JCYS70	0.25-0.30	18.5	0.75	70	0.75	1.5
JCYS80	0.35-0.40	22	1.1	80	0.75	1.5
JCYS90	0.50-0.60	37	1.1	90	1.1	2.2
JCYS120	0.70-0.80	55	1.1	120	1.1	2.2
JCYS135	1.0-1.5	75	1.5	135	2.2	2.2
JCYS160	1.8-2.5	90	2.2	155	2.2	3.5
JCYS200	3.0-4.0	132	2.2	195	3.0	4.5
