Specifications
The running costs ofIndustrial Air Conditioner
are approximately 1/10th of those
to operate than
refrigerative air con.
The new industrial evapoative air cooler
Model: AZL18-ZX10E
Characteristics
1.Streamline design,durable and beautiful appearance
2.Swirl designed drain outlet,easy to let off sewage
3.With integrate and special triangle water distribution structure,making the water distribute evenly
4.with concealed design,the water will not enter into the cooler when the pipe is accidentally detached or broken
5.With a damper to prevent warm air leakage in winter
6.With a outside dust screen which can be easily removed and cleaned
7.Using intelligent LCD controller,which is easy to operate and understand
8.The casing is made of high strength weather ability polymers which is UV-proof,anti-aging,and resistant to deformation
9.Using specially designed axial fan,with large airflow,low noise,energy-saving and large application.
10.Using high quality aluminum housing motor,with good heat dissipation,high protection grade,waterproof and moisture-proof
Specification
| Specification | AZL18-ZX10E |
| Airflow (m3/h) | 18000 |
| Pressure (Pa) | 190 |
| Output(kw) | 1.1 |
| Power Resource (V/Hz) | 220/50 |
| Rated Currency (A) | 5.6 |
| Fan Type | Axial |
| Vent size(LxW)(mm) | 655*655 |
| Fan Speeds | 1-phase,multi-speeds |
| Noise (dBA) | ≤76 |
| Dimension (LxWxH)(mm) | 1150*1150*950 |
| Pad size(LxWxH)(mm) | 620*830*100 |
| Net Weight (±3kg) | 80 |
| Operation Weight (kg) | 110 |
| Intellingt Cleaning | Optional |
| Water Lack Protection | approval |
| Controller | LCD |
| Pre-dust Filter | Optional |
| Exhaust | Optional |
| Pre-cooling | Optional |
| Group-control | Optional |
| Damper | approval |
