Diesel engine wood chipper, CE approved

Specifications

Durable Chromium CR-12 blades.
Maintenance simple,low noise.
High efficiency 10-12m3/H.
CE approved(CE No. --110727/WFA516)

1. Durable Chromium CR-12 blades.

2. Maintenance simple,low noise.

3. High efficiency 10-12m3/H.

4. CE approved(CE No. --110727/WFA516)







 Features:



1. Yanmar or Changchai 40hp/30HP/22HP/18HP diesel engine.



2. 8 inch(1-25cm) Max. chip capacity, chip size 10-50mm adjustable.



3. High quality CR-12 material cutting blades



4. 3 blades, round disc housing, easy to change blades and belts.



5. Double hydraulic feeding rolls, round flywheel house, hydraulic tank, gear pump,

    protect safty guard optional.



6. Free flow valve added on the new model wood chipper.



7. discharge hood can rotate in 360 degrees



8. optional color according to specific requirement.



9. 2" hitching ball, can use in Europe, Australia, USA etc.



10. Jockey wheel, road/turf tyre



Usage:



1. The small chips made by the wood chipper can be used for animal bedding, for the forestry and

soil protecting, for new energy making, for compost and for charcoal.



2. Some customers use their colored garden waste chips, cover the soil and made the garden

beautiful; some of them use the garden waste chips in the fireplace.





Technical specification of diesel engine wood chipper:



Model	DH-18/DH-22	DH-30/DH-40
Power	18hp/22hp	30/40hp
Engine	one cylinders Electric started diesel engine	3cylinders Electric started diesel engine
Chipper capacity	8”diameter/200mm	8" diameter/200mm
Feeding system	Mechanical / hydraulic	Hydraulic
Rotor plate size	640mm	760mm
Rotor plate weight	85kg	85kg
Knives number	1stationary knife:2rotor knives	1stationary knife:2rotor knives
Blade Material	Durable Chromium CR-12	Durable Chromium CR-12
Dimensions(Hopper discharge)	1300x1400x1100mm	1900x1300x2500mm
Feed Hopper inner Opening	200x220mm	500mmx500mm
Discharge Hood Height	1800mm	2000mm
Rated RPM	1080	1280
Discharge hood rotates	360 degree	360 degree
Settings	turning lights, easy discharge hood,2”Ball Hitch, Safety Chains and leaf spring on axle
Gross Weight	680kg/720kg	780kg (1720LBS)
Working efficiency	6-10CBM/H	10-12CBM/H









Note: DH-30 and DH-18, DH-22 outlook is the same with DH-40, only the engine is difference.
