Electric Insect Killer Lamp

Name: Frequent Vibration Insecticidal lamp

Model: TPSC1 series/ TPSC2 series

1. Introduction

Insecticidal lamp with solar energy frequent vibration will transform optical energy into electrical energy through solar panel, output safe voltage, save energy and electricity and cost little, which provides advanced and protested tool for pest control areas where lack of electrical energy so that they have to give up trapping pests.

2. Characteristics

1) Frequent vibrated induced control technology

2) Light source: frequent vibration tube ( wavelength: 320~600μm)

3) Impact area: ≥0.16m2

4) Protect for network flow short circuit

5) Make the cross network spiral winded to avoid short circuit; the distance between networks is alternative. (generally ≤ 10mm)

6) Light control: auto-shut up and down according to day and night

7) Auto-protection in rainy days: when humidity above 95% RH, the frequent vibration lamp will be in the state of auto-protection, or it will work normally.(TPSC-2)

8) Insulation column: high-temperature: 1000°C ; corrosion resisting and high pressure resisting; in rainy days, pull arc in high pressure network 30min continuously; the insulation column no carbonization.

9) Control area: 30~60 mu

3. Technical Parameters

Power: AC185-265V, 50HZ

Network voltage: 2-3KV

Insulation resistance: ≥2.5M

Rate: ≤25W

Life span: 3~5 years

Light source: 15 W wavelength trapped tube; Electronic ballast can be started instantly.

4. Model Difference
