Alien H3 Long Distance Passive RFID UHF Inlay

Antenna Width

3.66” [93.0mm]

Antenna Length

0.748” [19.0mm]

Web Width (-FR)

4.173” [106.0mm]

Web Width (-FSR)

3.799” [96.5mm]

Web Pitch

1.0” [25.4mm]

Core Width (-FR)

3.799” [96.5mm]

Core Width (-FSR)

4.173” [106.0mm]

Core ID

6” [152.4mm]*

Core Material

Fiberboard

Interleaf Material

Paper

Interleaf Width

1.5” [38.1mm]

Inlays per Roll

12,500 Nominal

Maximum Roll OD

< 12” [304.8mm]

Roll Labeling Data

Roll #, Quantity

Inlay Width

3.799” [96.5mm]

Inlay Length

0.913” [23.2mm]

Web Width

3.925” [99.7mm]

Web Pitch

1.0” [25.4mm]

Core Width

3.874” [98.4mm]

Core ID

6” [152.4mm]*

Core Material

Fiberboard

Inlays per Roll

12,500 Nominal

Maximum Roll OD

< 16” [406.4mm]

Roll Labeling Data

Roll #, Quantity

White

TT Printable White Film Only

Overlay Adhesive

General Purpose Permanent

Inlay Adhesive

General Purpose Permanent

Adhesive Application Temperature

> +25ºF [-4ºC]

Adhesive Service Temperature

-40ºF to +200ºF

[-40ºC to +93.3ºC]

Release Liner

40# SCK

Shelf Life

2 years at +77°F [+25°C] @

40%RH

Recommended Storage

+77ºF [+25°C] @ 40% RH

Storage Limits

-13°F to 122°F

[-25°C to +50°C]

20% to 90% RH

Non-condensing

Operating Limits

-40°F to +158°F

[-40°C to +70°C]

20% to 90% RH

Non-condensing

Bend Diameter

> 1.97” [50mm]

Pressure

< 5N/mm2

Drop Resistance

Per ASTM D5276

Write Cycles

10,000 @ 25°C

RoHs

2002/95/EC, 2005/618/EC,

2011/65/EU Compliant

REACH

1907/2006/EC Compliant

ESD Limit– HBM / CDM

5.0kV / 1.5kV

Protocols Supported

ISO/IEC 18000-6C

EPCglobal Class 1 Gen 2

Integrated Circuit

Alien Higgs-3

EPCglobal Certificate

950110126000001084

Operating Frequency

840--960 MHz

EPC Size

96--480 Bits

User Memory

512 Bits

TID

32 Bits

Unique TID

64 Bits

Access Password

32 Bits

Kill Password

32 Bits
