hexagonal netting for poultry (Factoryof Guangzhou)

Specifications

hexagonal netting for poultry
1.Electro galavanized wire
2.Hot dip galvanized wire
3.Pvc coated wire
4.ISO9001:2008

  hexagonal netting for poultry (Factoryof Guangzhou)



Hexagonal  Netting is also known as Chicken Netting, or Hexagonal Wire.It is made from low carbon steel wire, stainless steel wire

 Weaving pattern;straight twist, reverse twist, doubledirection twist, Weaving before galvanized, weaving after galvanized.

Electro galvanized, hot dipped, plastic-coated, stainless steel, PVC coated, etc.
Characteristics:



The hard structure, flat surface, corrosion-resisting and oxidation-resisting.
Applications:



used for feeding Chicken, ducks, gooses, rabbits and the fence of zoo,machinery protection, speedway's fencing, stadium' purse net,

 the evanescence belt protection mesh on the road. If we use the mesh to make container boxlike, then fill the container with riprap,

 it could be used for protecting and holding out the sea wall, hillside, bridge and other related civil engineering,

it is the superior material for flood control.



Specifications:



Hexagonal Wire Netting
Mesh			Min. Gal.v.G/SQ.M		Width		Wire Gauge (BWG)
Inch	mm	Tolerance(mm)
3/8"	10mm	±1.0		0.7mm - 145		2' - 1M		27, 26, 25, 24, 23
1/2"	13mm	±1.5		0.7mm - 95		2' - 2M		25, 24, 23, 22, 21
5/8"	16mm	±2.0		0.7mm - 70		2' - 2M		27, 26, 25, 24, 23, 22
3/4"	20mm	±3.0		0.7mm - 55		2' - 2M		25, 24, 23, 22, 21, 20, 19
1"	25mm	±3.0		0.9mm - 55		1' - 2M		25, 24, 23, 22, 21, 20, 19, 18
1-1/4"	31mm	±4.0		9mm - 40		1' - 2M		23, 22, 21, 20, 19, 18
1-1/2"	40mm	±5.0		1.0mm - 45		1' - 2M		23, 22, 21, 20, 19, 18
2"	50mm	±6.0		1.2mm - 40		1' - 2M		23, 22, 21, 20, 19, 18
2-1/2"	65mm	±7.0		1.0mm - 30		1' - 2M		21, 20, 19, 18
3"	75mm	±8.0		1.4mm - 30		2' - 2M		20, 19, 18, 17
4"	100mm	±8.0		1.6mm - 30		2' - 2M		19, 18, 17, 16









.





packing of product

 uses of product

The production process



About US

NIAN FA wire mesh factory has specialized in weaving and fabricating industrial wire cloth more than 12years

since china reform to outside country. The wire cloth is an essential commodity of most industrial manufacturing area,

we offer a complete range of opening woven wire cloth to close tolerances from any ductile metal or alloy that can be

drawn into wire. Extremely in the stainless steel wire cloth, with our 12years experience we be able to supply the most

wire cloth among the current market.

We welcome your special requirements about both specification and packing method

If you want to know more about our products, welcome to contact us!
