Labrotary and Industrial Evaporator PromotionRE-52A Efficient Economic Vacuum Evaporators

Capacity: 250ml, 500ml, 1L, 2L,3L,5L,10L,20L,30L,50L

Down Mode: Manual lifting and electric lifting

Temperature: RT~99(water bath) RT~180(Oil bath)

PTFE discharge valve, corrosion resistance, pollution-free

vacuum distillation equipment

Lab Vacuum Rotary Evaporator

Working Principle of Rotary Evaporators:

The equipment for purification distillation test rotates and shapes a thin film in negative pressure condition by heating, evaporates efficiently, and then condenses and recollects solvent to purify and separate.

Brief Introduction of Rotary Evaporators:

1. A rotary evaporator ( Rotary Vacuun Evaporator, Rotavapor, Rotavap, Rotovap ) is a device used in chemical laboratories for the efficient and gentle removal of solvents from samples by evaporation.

2. Large capacity, large diameter rotary evaporator flask, evaporation area, the vacuum water bath, while rotating edge heating, evaporation of the solution diffusion efficiency can be used for biological, pharmaceutical, chemical, food and other small scale areas, Chinese and production.

3. Rotary Evaporators with recycled water multi-use vacuum pumps, diaphragm pumps, low temperature cycle (vacuum) pumps, circulating cooler, constant temperature circulator, low temperature cooling liquid circulating pump and other devices supporting component systems.

Feature of Lab rotary evaporator:

1. High evaporation, high recovery, conversion and use of advanced electronic speed control to ensure stable operation of the motor;
2. Bath list the pot, reduce breakage, evaporation of low boiling point, the collection bottles can be immersed in an ice bath to reduce the secondary evaporation;
3. Collection bottle milling port connection, can be easily removable, sealing the fine;
4. High temperature long- lasting sealing, dynamic sealing system to ensure high temperature corrosion resistance and long list, particularly good air tightness
5. Japanese technology AC induction motor, variable speed, no brush no spark, can work effectively for a long time.
6. Chassis, bath pot, main bar, stainless steel shaft made of high quality, attractive appearance corrosion;
7. Intelligent temperature control, water and oil bath dual-use, more widely used. Temperature fluctuation is only 0.2 degree, evaporation is more stable, not easily washed material;
8. Whole series modular design, scalability, easy instabllation and maintenance;
9. According to user needs, electrical part can be produced with explosion-proof configuration

Application of Lab rotary evaporator:

   Rotary evaporator is mainly used for pharmaceutical, chemical and bio-pharmaceutical industry concentration, crystallization, drying, separation and dissolution of coal recovery. The principle is: in a vacuum condition, constant temperature heating, to rotate bottles constant rotation, the material in the sidewall formation of large area thin film, high evaporation. Solubilization by high glass condenser vapor cooling, recovery in the collection bottle, greatly improve the efficiency of evaporation, particularly easy to use in high-temperature decomposition of the variability of biological products was concentrated and purified.

Small size of rotary evaporator for lab:

Photo of rotary evaporator:

Pilot-scale of rotary evaporator:

Photo of more rotary evaporator:

Structure of Rotary Evaporator:

Spare parts of Rotary Evaporator:

Packing of Rotary Evaporator:

Service of rotary evaporator:

1L, 2L, 3L, 5L, 10L, 20L, 30L,50L Rotary Evaporator can be provided by us. You can choose the rotary evaporator with water bath or oil bath.

Rotary Evaporator with Discharging Valve, easy for collecting material and clean !!!

We believe the quality will not let you down !

Customized Glass Reactor also welcome here !!!

TOPTION---Your top option !

Certificate of rotary evaporator

Trade terms of rotary evaporator:
