8 ALAFY-420 Automatic Weighing Packaging Machine for potato chips

export plywood case for automatic weighing bag machine

Specifications

automatic weighing packing machine
1.auto feeding,weighing, packing, print
2. touch screen
3.chips, nut, candy, etc



 ALAFY-420 Automatic weighing and packing machine





1. Description:



Our Industrial Weighing Packing Machine is suitable for automatic packaging particle like sweets, beans, peanuts, seeds,

grain, biscuits, nuts, tea, dumplings, gourmet, coffee, sugar,fastener and so on. It is composed by auto lifter, auto weighing,

working platform, auto packing part, finished products conveyor part. Very convenient and popular.



2. Features:



1.Imported PLC control system, simple-operating, visual touch screw.
2.Servo film feeding system, correct register, sealing and cutting positions adopt automatic correction device.
3.Intelligent temperature controller is used, correct temperature control, ensure nice, smooth seal.
4.Perfect automatic alarming protective function, reduce the consumption up to the lowest.
5.When the machine is combined with metering equipments, full packaging process including automatic feeding, metering,

bag filling, date printing and automatic counting is completed.
6.Type of bag making: according to customer's demand, the machine can produce pillow bags, punched hanging bags.



3. Main Technical parameter:



Packing speed	30-45 bags/min(according to material&film quality)
Bag-making size	(L80-300mm (W)50-200mm
Filling range Max	2000ml
Packing materials	OPP/CPP PET/PE and other composite material
Film width Max	420mm
Film thickness	0.06-0.12mm
Air consumption	0.8Mpa 0.8m3/min
Power supply	AC220V 50/60Hz 4kw
Machine height	3.955m
Precision	≤±1.5%





4. Pictures for reference:
