Polypropylene Material and Geogrids Type biaxial geogrids for roads and gabion and mattress
USD $0.12 - $2.1
/ Square Meter
5000 Square Meters(Min.Order)
- 60000 Square Meter / Square Meters per Month
- Qingdao Shanghai Tianjin
- T/T Credit Card
You May Like
Product Details
| Place of Origin: | Shandong, China | Brand Name: | BPM | Model Number: | TGGS-Polyester Geogrid |
| Material: | Plastic |
Product Description
PP Biaxial Geogrid
Introduction :
The properties of Biaxial Geogrids, made in Polypropylene (PP) with their square apertures, high tensile strength and optimised geometry of nodes and ribs make them equal to any other similar material. The reinforcing action of PP Biaxial Geogrids lies mainly in confining soil and increasing its shearing resistance by a process of interlocking between the square ribs and the soil. The load dispersal effect from the interlocking mechanism is highly effective and can reduce sub-base thickness and construction cost. PP Biaxial Geogrids can be used with any kind of mechanical fill material. Two aperture size ranges are available for optimum matching with project fill. Standard Roll Dimensions
Technical parameter :
| Index Properties | Test Method | Unit | GG1515 | GG2020 | GG3030 | GG4040 |
| MD TD | MD TD | MD TD | MD TD | |||
| Polymer | -- | -- | PP | PP | PP | PP |
| Minimum Carbon Black | ASTM D 4218 | % | 2 | 2 | 2 | 2 |
| Tensile Strength@ 2% Strain | ASTM D 6637 | Kn/m | 5 5 | 7 7 | 10.5 10.5 | 14 14 |
| Tensile Strength@ 5% Strain | ASTM D 6637 | Kn/m | 7 7 | 14 14 | 21 21 | 28 28 |
| Ultimate Tensile Strength | ASTM D 6637 | Kn/m | 15 15 | 20 20 | 30 30 | 40 40 |
| Strain @ Ultimate Strength | ASTM D 6637 | % | 13 10 | 13 10 | 13 10 | 13 10 |
| Structural Integrity | ||||||
| Junction Efficiency | GRI GG2 | % | 93 | 93 | 93 | 93 |
| Flexural Rigidity | ASTM D 1388 | Mg-cm | 700000 | 1000000 | 3500000 | 10000000 |
| Aperture Stability | COE Method | mm-N/deg | 646 | 707 | 1432 | 2104 |
| Dimensions | ||||||
| Roll Width | -- | M | 3.95 | 3.95 | 3.95 | 3.95 |
| Roll Length | -- | M | 50 | 50 | 50 | 50 |
| Roll Weight | -- | Kg | 39 | 50 | 72 | 105 |
| MD denotes Machine direction. TD denotes transverse direction. | ||||||
Applications:
Make reinforce treatment for various kinds of soft soil foundation to evenly distribute load stress and reduce uneven settlement, not easy to generate static electricity, and flammability property good in the coal mine. It is easy to wash coal.
Used in highway, railway, port, airport and municipal project. Support in the recovery working face of coal mine and roadway in the coal mine.
Function:
1. Improving bearing capacity of road foundation and prolong its service life
2. Preventing road surface from subsiding and cracking
3. Be convenient for construction, reducing cost and maintaining expense for the project
4. Providing stability for slopes and avoid the losing of the water and soil
