Ozone generator for livestock lagoons1. enamel corona discharge ozonizer
2. water sterilization machine
Ozone generator for livestock lagoons
Features:
1. Carbon steel sprayed with plastic of machine housing.
Most suitable used for water treatment, eg: sewage water treatment, drinking water, industrial water treatment etc.
2. Installed with NT-PC10-60G/Hr enamel ozone generator tube
Water cooled for internal & external electrodes, effective prevent high temperature rising during ozone tube’s operating, for ensuring high ozone concentration output.
3. Adjustable ozone output
Use high-frequency & intelligent power supply inverse system, ozone output can be adjusted for different usage.
4. Can be feed with outside oxygen/air feed, also models with air compressor.
5. High ozone concentration is more than 90Mg/L if connect with outside oxygen tank.
6. Easy to maintain and assembly.
Controls:
Gas flow meter Voltmeter Ampmeter On/Off
Working indicator Power indicator Ozone Output Adjuster
Pressure regulator Alarm Emergency
Water flow switch
Speicifications for NT-WZQ water treatment ozone machine:
Item | Unit | NT-WZQ 10g | NT-WZQ 20g | NT-WZQ 30g | NT-WZQ 50g | NT-WZQ 60g |
Oxygen flow rate | L/Min | 1-4 | 3-10 | 3-6 | 6-15 | 8-18 |
Ozone concentration | Mg/L | 100-66 | 104-51 | 120-94 | 115-65 | 90-58 |
Ozone output | g/hr | 6-15.80 | 18.72-30.60 | 21.6-33.84 | 41.40-58.50 | 43.2-62.64 |
Power | KW | 0.40 | 0.40 | 0.60 | 0.60 | 1.30 |
Frequency | KHZ | 6 | ||||
High voltage output | V | PP3600V | ||||
Power amplification | A/V | IGBT 50A/600V | ||||
Way of cooling | Water cooled for internal & external electrodes | |||||
Cooling water flow rate | L/Min | 4 | 4 | 5 | 6 | 10 |
Cooling water temperature | °C | 30 | ||||
Adjustable(Variable control) | % | 20-100 | ||||
Power supply | V/HZ | 220v/110v 50/60HZ | ||||
Dimension | mm | 460×385×840 | ||||
