Waste cable stripping machine
- 100 Set / Sets per Month
- Qingdao Shanghai Tianjin Shenzhen Guangzhou
- T/T L/C D/P D/A Credit Card PayPal
Product Details
| Place of Origin: | Henan, China | Brand Name: | YW | Model Number: | 918-A |
| Usage: | Stripping |
Packaging Details
waste cable stripping machine is packed by wooden case
Product Description
waste cable stripping machine
Basic Parts of waste cable stripping machine:
1. Entry capstan: it can deliver wires and strip out the wire heads
2. Wire wheel: it is used to deliver wires and strip out the wire ends
3. Entry capstan gap adjusting knob: it can adjust the entry capstan gap according to the wire size
4. Entry capstan pressure adjusting knob: it can adjust the entry capstan pressure according to the wire skin strength
5. Entry capstan uplift knob: when the wire stripping machine begins to thread wires, turn the knob to uplift the entry capstan, so the wires can go through; when the machine runs, turn the knob to put down the entry capstan and press the wires
6. Wire wheel gap adjusting knob: it can adjust the wire wheel gap according to the wire size
7. Wire wheel pressure adjusting knob: it can adjust the wire wheel pressure according to the wire skin strength
8. Wire wheel uplift knob: turn the knob to uplift the wire wheel before taking out the wires; when the wire stripping machine works, turn the knob to put down the wire wheel
9. Tool head assembly: it is used to cut off the wires, strip wire heads and ends. The up blade and under blade should open to
the largest state under the machine halt state, so the wires can pass through tool smoothly
Technical Parameters of waste cable stripping machine:
Model No. | 918-A | 918-F | KA | KOB | 918-B |
Dia. of Wire Processed | 1-25mm | 1-30mm | 1-35mm | 1-42mm | 2-90mm |
Cutting Speed | 30m/minute | 30m/minute | 30m/minute | 30m/minute | N/A |
Voltage | 220v/380v | 220v/380v | 220v/380v | 220v/380v | 220v/380v |
Power | 1.5kw | 1.5kw | 2.2kw | 2.2kw | 3kw/4kw |
Dimensions (cm) | 55*51*84 | 56*55*84 | 60*58*84 | 70*61*84 | 80*58*120 |
Weight | 60kg | 70kg | 80kg | 110kg | 200kg |
Productivity (kg/10H) | 100-300 | 150-300 | 400-1000 | 600-1500 | 800-2000 |
All produts purchased in our company are guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free.
a, Before sending the machine, we will test and adjust, so you can use directly when you get it. b, Operation video & instruction will be sent to clients, to help them use the machines better.
Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we will solve your problems in time. If you are caught in some problems when using our products, welcome to contact us at any time.
a, Any problems occur while using, professional advice will be offered. b, All kinds of frequently used parts are supplied all the year round. c, 24 hours hot line +86-18137122335
