small auger for cement delivery
- 200 Set / Sets per Month
- Qingdao
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | DOM | |
| Model Number | 219*6 |
Product Description
small auger for cement delivery
| Features |
1. Adopt high-quality steel pipe with good integral rigidity.
2. Adopt double-pitch paddles, which decrease the compression degree of material when being transported, and avoid blocking.
3. Adopt high-quality reducer with heavy-duty design, large torque and low noise.
4. Adopt optional universal ball joint, which facilitates installation, adjustment and steering.
5. Inlet equipped with high quality middle-hoisting bearing and tail bearing.
6. Sufficient spare parts with complete specification.
7. Large stock for common diameter of 165,219,273, 323 and 407, and dimension & angle can be customized according to your requirement.
8. Assembled by standard parts and components, which makes it convenient for transportation.
| Dimension |
Outer pipe Diameter D | Diameter of Inlet flange | Height of Inlet | Height of outlet | ||||||
A | B | C | 0-20° | >20-40° | >40-50° | 0-20° | >20-40° | >40-50° | |
H1 | H1 | H1 | H2 | H2 | H2 | ||||
140 | 200 | 250 | 280 | 400 | 450 | 500 | 250 | 300 | 350 |
168 | 200 | 250 | 280 | 400 | 450 | 500 | 250 | 300 | 350 |
219 | 300 | 350 | 380 | 500 | 550 | 600 | 300 | 400 | 450 |
273 | 300 | 350 | 380 | 500 | 600 | 700 | 350 | 450 | 500 |
323 | 300 | 350 | 380 | 550 | 700 | 800 | 400 | 500 | 600 |
407 | 470 | 470 | 530 | 750 | 900 | 1000 | 450 | 600 | 700 |
| Technical data |
Diameter 168mm | Diameter 273mm | ||||||
Length (m) | Reducer | Speed Ratio | Motor Power (KW) | Length (m) | Reducer | Speed Ratio | Motor Power (KW) |
3 | SD1500 | 5/28 | 4 | 3 | SD2000 | 7/38 | 5.5 |
4 | SD1500 | 5/28 | 4 | 4 | SD2000 | 7/38 | 7.5 |
5 | SD1500 | 5/28 | 4 | 5 | SD2000 | 7/38 | 7.5 |
6 | SD1500 | 5/28 | 5.5 | 6 | SD2000 | 7/42 | 11 |
7 | SD1500 | 5/28 | 5.5 | 7 | SD2000 | 7/42 | 11 |
8 | SD1500 | 5/28 | 5.5 | 8 | SD2000 | 7/42 | 11 |
9 | SD1500 | 5/28 | 5.5 | 9 | SD2000 | 7/42 | 15 |
10 | SD1500 | 5/28 | 7.5 | 10 | SD2000 | 7/42 | 15 |
11 | SD1500 | 5/28 | 7.5 | 11 | SD2000 | 7/42 | 15 |
12 | SD1500 | 5/28 | 7.5 | 12 | SD2000 | 7/42 | 15 |
13 | SD1500 | 5/28 | 7.5 | 13 | SD2000 | 7/48 | 15 |
14 | SD1500 | 5/28 | 7.5 | 14 | SD2000 | 7/48 | 18.5 |
Diameter 219mm | Diameter 323mm | ||||||
Length (m) | Reducer | Speed Ratio | Motor Power (KW) | Length (m) | Reducer | Speed Ratio | Motor Power (KW) |
3 | SD1500 | 5/28 | 4 | 3 | SD2000 | 7/38 | 7.5 |
4 | SD1500 | 5/38 | 5.5 | 4 | SD2000 | 7/42 | 11 |
5 | SD1500 | 5/38 | 5.5 | 5 | SD2000 | 7/42 | 11 |
6 | SD1500 | 5/38 | 7.5 | 6 | SD3000 | 7/42 | 15 |
7 | SD1500 | 5/38 | 7.5 | 7 | SD3000 | 7/42 | 15 |
8 | SD1500 | 5/38 | 7.5 | 8 | SD3000 | 7/48 | 18.5 |
9 | SD1500 | 5/42 | 11 | 9 | SD3000 | 7/48 | 18.5 |
10 | SD1500 | 5/42 | 11 | 10 | SD3000 | 7/48 | 18.5 |
11 | SD1500 | 5/42 | 11 | 11 | SD3000 | 7/48 | 22 |
12 | SD1500 | 5/42 | 11 | 12 | SD3000 | 7/48 | 22 |
13 | SD1500 | 5/42 | 15 | 13 | SD3000 | 7/48 | 22 |
14 | SD1500 | 5/42 | 15 | 14 | SD3000 | 7/48 | 22 |
