Home > Products > Twin Shafts Mixer > electric mobile concrete mixer for industrial

electric mobile concrete mixer for industrial

FOB Price

USD $1 - $13,538 / Set

1 Set(Min.Order)

Supply Ability 15 Set / Sets per Month
Port any port of china
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Shandong, China
Brand Name	DOM	Model Number	KTSA 2000
Mixing Power	37*2 Kw	Charging Capacity	2000 L
Reclaiming capacity	3000 L	Speed of Mixing Drum	80/100-150
Water Supply Mode	Water Pump	Outline Dimension	3460x2320x2140 mm
After-sales Service Provided	Engineers available to service machinery overseas	Working Cycle Period	30s

Product Description

electric mobile concrete mixer for industrial

Brief Introduction

The twin shaft mixer have two shafts,increase the mixing capacity.It can work under any circumstances, the wet, dust, temperature and other environmental conditions without strict requirements, but also applicable to outdoor work

Our factory

Technical parameters

Model	KTSB1000	KTSB1250	KTSB1500	KTSA2000	KTSA2500	KTSA3000	KTSA3500	KTSA4000	KTSA4500
Charging Volume(L)	1500	1750	2250	3000	3750	4500	5300	6000	6750
Discharging Volume(L)	1000	1250	1500	2000	2500	3000	3500	4000	4500
Max of Aggregate(mm)	80/100	80/100	80/100	80/100	80/100	80/100	80/100	80/100	80/100
Weight(T)	5.2	5.5	5.8	7.5	8.5	9.2	9.6	12.2	12.5
Motor Power(KW)	18.5x2	22x2	30x2	37x2	45x2	55x2	55x2	75x2	75x2
Dimension(mm)	2810x2000 x1920	3020x2000 x1920	3230x2000 x1920	3460x2320 x2140	3670x2320 x2140	3880x2600 x2200	4100x2600 x2200	4670x2600 x2200	4890x2600 x2200
Mix Time	≤30	≤30	≤30	≤30	≤30	≤30	≤30	≤30	≤3

Product detail

Speed Reducer:

The speed reducer adopts Italy-imported original or home-produced fitting parts,with reliable performance,long service life and low noise.

Shaft-End Seal:

Adopts original-imported parts assembled multi-shaft-end seal in shaft end and avoids cement&mud approaching to shaft end to extend service life of the concrete mixer.

Electric Lubricating Oil Pump:

Supply oil to four shaft end respetively with using four pump cores.It is no need to use flow divider valve but to avoid blocking of the flow divider valve to decrease the workload of maintenance and service.

Discharging Device:

Hydralic discharging system,with strong drive force and reliable discharging.Discharging door can be opened at any angle,with manual discharging function.The discharging door adopts detachable structure which is convenient for maintenance.

Company information

Taian Shizhe Trading Company established in 2011 is engaged in import and export trading. It is the international trading department of Shandong DOM Machinery Equipment Co., Ltd. We mainly conduct business including domestic and foreign trading, such as concrete mixing plant, concrete mixers, Chinese-foreign cooperative producing, and entrecote trading. Our manufacture mainly produces concrete batching plant, asphalt plant, brick production line and related equipments of construction. Concrete mixer, screw conveyor, cement silo and accessories have always been our hottest products for export. Besides, the small concrete tools such as concrete vibrator, concrete vibratory screed, tamping rammer, plate compactor, concrete cutter also belong to hot product. Besides, we purchase kinds of products in China for our customers.
