high quality microwave ldr sensor

Specifications

Idr sensor
1.white/black
2.light control:10 to 2000lux(adjustable)
3.detection distance:1-8m(radius) adjustable

high quality microwave ldr sensor



1.detail description



1.power sourcing: 220 to 240v/ac
2.frequency: 50hz

3.detection angle: 360°/180°



4.detection range:1-8m(radius)adjustable

5.transmission power:<10mw

6.hf systerm:5.8ghz cw radar,ism band



7.maximum rated load:

1200w (incandescent lamp) 300w (energy-saving lamp)

8.time setting: delay times: min.:10sec±3sec max.: 12min±1min

9.light control:3 to 2000lux (adjustable)

10.installation height:1.5~3.5m

11.detection motion speed: 0.6~1.5m/s

12.power consumption:0.9w



ction:

• detection field: the wide detection range is made up of up and down, left and right (see the following diagram), the detection range could be adjusted according to your desire, but the moving orientation in detection field has great relation with the sensitivity.
• identify day and night automatically: the ambient light of st09 could be adjusted according to your desire: when turn to sun (max), it will work day and night, when turn it to moon (min), it will only work in the ambient light less than 3lux. as for adjustment, please refer to testing way.
• time-delay is added continually: when it receives the second induction signals after the first induction, it will compute time once more on the rest of the first time-delay basis (set time).
• time-delay is adjustable: it can be set according to your desire.

3.packing details



we usually use color box.if you have special packing requirements,pls inform us in advance.

packing	color box
inner box(pcs)	1
outer box(pcs)	50
gross weight(kg)	14.0
meas't(cbm)	0.061



                      ningbo hunshine international trading co.,ltd.



we have many years experience to export lighting products to more than 50 countries . if you want more detailed information of this product or related products,please contact us, we will reply as soon as possible (general in 24 hours).
