New Condition pp Yarn Multifilament Making Machine Line 008618853866282

New Condition pp Yarn Multifilament Making Machine Line 008618853866282 photo-1
US$ 50,000 - 80,000 MOQ: 2 Sets
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Plastic Rope
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Product Type Plastic Rope
Place of Origin Shandong, China
Brand Name ROPE NET
Model Number RMYS-161
Voltage 380V
Power(W) 300W
Dimension(L*W*H) 1000*1100*6150mm
Weight 6500KG
Certification CE ISO
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Product Application

The machine can produce different size of PP FDY yarn which is widely used in rope,net,twine,webbing,garments etc.The machine has the characteristics of high efficiency,high strength,long life span,easy maintenance.

This machine is used for FDY making, with new design screw, yarn scope is from 150D to 3000D. Supply customer good spinning equipment for high tenacity industry filament. The machine has feedback control system with AC inverter , imported instrumentation and automatic take-up winder, also with specialized symmetrical structure design and energy saving cooling system, easy to maintain.

SPECIFICATIONS FOR RMYS-161


General introduction
Yarn size range
d
500-1000d
tenacity
g/d
6.7-7.5 g/d
 Output
kg/hr
1752 kg/24hr


Main parameters

spinning speed
m/min
2200m/min
Install capacity
kw/v
89kw/220v
Machine size
mm
6000*5500*7000mm


Specifications
Daily Capacity
ton
1.8-2.6ton
Diameter of screw
mm
90mm
No. of bobbin
pcs
6/3/2/1

Main Features


Certifications
Detailed Images

Machine Parts

Name : Extruder

Brand : ROPENET

Original : CHINA

1.Screw diameter Ф90 L/D=30
2.heating power 35kw
3.drive power 18.5kw/380v

Main Features

Name:Filter and pipe
Brand:ROPENET
Original:CHINA
1.4-20mA pressure measurement and feedback
2.Double filter element heating power 12kw/220v

Machine Parts

Name:Spinning beam
Brand:ROPENET
Original:CHINA
1.heating by heat transfer oil
2.heating power 8kw/220v

Main Features

Name:Winder
Brand:ROPENET
Original:CHINA
1.SLW 1200/6,1500-2800M/min
2.Paper bobbin size Ф125 mm x Ф110mm x 200mm
3.Maximum yarn spool size Ф430mm x Ф125mm x 170mm (13kg max)

Our Service

Installation Service

We will provide the technical know-how for your operation smooth transition and support for installing, debugging, operation of the machine, it will indicate you how to use this machine well.

After-Sales Service

Consequently we offer comprehensive maintenance options to prevent equipment issues before they become problems. Also we offer one year guarantee period.

Packing & Delivery
Packaging
Size
1000X1150X1500mm
Weight
0.8T



Packaging Details
Package according to customers special request.
Packaging
Size
5000X1200X1200mm
Weight
1.2T



Packaging Details
Package according to customers special request.
