Stationary concrete mixing plant HZS90 with silo

FOB Price

USD $96,000 - $184,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Power Type	Electric
Place of Origin	Shandong, China	Brand Name	shandong lianchuang
Model Number	HZS90	Power(W)	112kw
Weight	52000kg	Certification	CE,ISO
Warranty	1YEAR	After-sales Service Provided	Engineers available to service machinery overseas

1.PLC control
2.good quality and after service
3.Very Competitive price
4.7-8 year export experience

1.Applied area

The concrete mixing plant of this series has intellectually automatic function. It belongs to intermittent forced mixing station.

It’s the ideal equipment for constructions of middle-small buildings,roads and bridges, the tube piles and cement precast factories.

2.Main parameter

Model	HLS60	HLS90	HLS120	HLS180
Rated productivity ( m³/h)	60	90	120	180
Matching mixer	JS1000	JS1500	JS2000	JS3000
Storage bin capacity (m³⁾	3×10	3×16	4×20	4×20
Discharging height (m)	3.8	3.8	3.8	3.8
Total power (kw)	78	112	150	198
Aggregate measuring accuracy (%)	±2	±2	±2	±2
Cement measuring accuracy( %)	±1	±1	±1	±1
Water measuring accuracy (%)	±1	±1	±1	±1
Fly ash measuring accuracy( %)	±1	±1	±1	±1
Additive measuring accuracy (%)	±1	±1	±1	±1
Total weight( Kg)	40000	52000	70000	85000

3.Main picture

4.Trade process
