HBTS90-18-176R Diesel Powered Concrete Pumps with Free Accessories
HBTS90-18-176R 90m3/h trailer pump is diesel engine powered, the core parts are imported while non-core parts adopts the well-known domestic brands.
Salient Features of 90m3/h trailer concrete pump for sale:
1. Power system adopts the domestic famous brand diesel engine
2. Using three-pump system, hydraulic loop does not interfere with each other ,the system runs stably , high reliability
3. With anti-pump function, to promptly eliminate the failure of blocking tube , for a short period of time and reliable downtime
Main Technical Data of HBTS90-18-176R 90m3/h trailer concrete pump
| Parameter Name | Unit | HBTS90-18-176R |
Overall performance | Max. Theoretical Concrete Output | M³/h | 98 |
Concrete Pumping Pressure | Mpa | 18 | |
The form of Distribution valve | S pipe valve | ||
Concrete Cylinder Spec.(bore*stroke) | mm | 200*1800 | |
Hopper Capacity | L | 700 | |
Diameter of Pump exit | mm | 180 | |
Hopper Height | mm | 1450 | |
Theoretical. Max. Delivery Distance (Vertical/ Horizontal) | m | 350/1500 | |
Power | The Model of Diesel Engine | Weichai Deutz 226B | |
Engine Power | Kw | 176 | |
Rated Speed | r/min | 2200 | |
Hydraulic Circuit Form | Opened-circuit | ||
Hydraulic System | Hydraulic pump | Rexroth 260 | |
Hydraulic oil tank capacity | L | 580 | |
Fuel tank capacity | L | 250 | |
Overall Dimension(L*W*H)) | mm | 6700*2160*2700 | |
Total Weight | Kg | 7600 |
- We have our own factory can provide stability quality, and also we can offer the most reasonable prices.
- We have our own professional sales teams who have rich experiences on the international trade and good technical knowledges.
- We have our own engineers who can install the mahines in abroad for the customers.
