China Supplier Bucket Lift Conveyor Price

Description

1. Bucket lift conveyor with Strong lifting capacity.

2. Wide range of applicable materials

3. Totall sealing structure.

4. ISO,TUV,SEW,FLENDER.

    China supplier bucket lift conveyor price

Application scope

TB series bucket lift conveyor is widely used in power plant, metallurgy, cement, chemical, light industry and so on. It is used for lifting  coal cinder ,piece coal, crushed stone, mineral stone, egg stone, dry and bulk and fluidity power, granular and block material  and so on. The material density is not more than 2 t/m³, the site temperature is not more than 250⁰C.

Operating principle

When the driving device start working , it drives the puley to make the chains with buckets to do the circular movement  from the below of the tail  to the top of the head  The head section has  outlet and the tail section has inlet.

The bucket is filled with material and run to the head section, then the material is thrown out from the outlet under the action of centrifugal force according to the parabolic design.With the running, the empty bucket is back to the below tail section and be filled material from the inlet again,then be lifted up to do parabolic discharge movement . So this cycle  finish the vertical transport of materials.

Features

1.It need small installation space and can lift more materials. it can convey the power, for example the calcined soda, salmiac, coal powder etc.

2.The transmission capacity is large. Lift the capacity up to 480 m³/h.

3.Long use life.

components

Site picture

Technical parameter

Packaging & Shipping.

1. Export packing.(Wooden case, carbon cast and pallet).

2. Container (as customer requirements).

3. It is suitable for long distance ocean transportation.

Our services

I.  Engineers abailable to service machinery overseas.

2. Provide installation guide, equipment manuals,  operation and repair training.

3. Provide random spare parts.

FAQ

Bucket elevator is not standard product, please tell us the following technical parameter before ordering:

Q: What 's the material will be lifted?please tell us more material features.

Q:What's the lifting height between the inlet with outlet?

Q:What's the lifting capacity do you want?

Company qualification certificate

Company advanced processing equipments

Company other informations

Welcome to consult us for more information.
