16x5x10 1/2 forklift solid tire
Specifications
for JLG Lifter;
tear and abrasion performance;
high safety coefficient;
long service life and economic effectiveness;
1. Solid rubb
2. Low rolling resistance
3. Puncture-free
4. Low energy consumption
5. This solid tire is suitable for the tow vehicles in airports, seaports, stations etc.
6. Strengthen wear resistance
7. High loading capacity
8. Better shock absorption and heat yield
9. OEM
3. Puncture-free
4. Low energy consumption
5. This solid tire is suitable for the tow vehicles in airports, seaports, stations etc.
JiNan time tires company has been engaging in tires line for more than 15 years, which has professional sales team.And friendly cooperate with a lot of well-known tyre factories in china. The main brands can be supplied are TRIANGLE, DOUBLE COIN, AEOLUS,LINGLONG, ADVANCED, HILO, DOUBLESTAR, ARMOUR, TAISHAN,etc.
More important,we have our owe brands TIANMING and TIME,has been exported to South America, Middle East Countries ,south Asia ,Africa etc,and established long-term cooperated dealer in more than 30 countries.
Our main products cover OTR tyre,TBR tyre ,AGR bias and radial tyre,PCR tyre ,SOLID tyre, ATV tyre,MOTOR tyre, and The products have passed ISO9001 quality system Certificate, ISO/TS16949 system Certificate. DOT Certificate, ECE Certificate, Inmetro Certificate, Soncap PC, GCC Certificate and BIS certificate etc.
We warmly welcome foreign friends to contact us for cooperation and developing flourishing future.
No. | Size of Tire | Net Weight(Kg) | Max Load (Kg) | ||||||
| Counter Balance Lift Trucks | Other Industrial Vehicles | ||||||||
| Inch | Millmeter | Types of Pattern | 10km/h | 16km/h | |||||
| (in) | (mm) | ±1.5%kg | Driving | Steering | Driving | Steering | 16km/h | ||
| 1 | 9x5x5 | 228.6x127x127 | SM | 6.50 | 890 | 790 | 785 | 715 | 685 |
| 2 | 10x4x6 1/2 | 254x101.6x165.1 | SM | 6.00 | 720 | 640 | 635 | 580 | 555 |
| 3 | 10x5x6 1/2 | 254x127x165.1 | SM | 7.40 | 940 | 835 | 830 | 755 | 725 |
| 4 | 10x6x6 1/2 | 254x152.4x165.1 | SM | 9.00 | 1160 | 1035 | 1030 | 935 | 895 |
| 5 | 10 1/2x5x5 | 266.7x127x127 | SM | 8.00 | 1020 | 910 | 905 | 820 | 785 |
| 6 | 10 1/2x6x5 | 266.7x152.4x127 | SM | 10.40 | 1295 | 1155 | 1145 | 1040 | 995 |
| 7 | 10 1/2x5x6 1/2 | 266.7x127x165.1 | SM | 8.20 | 1000 | 890 | 885 | 805 | 770 |
| 8 | 10 1/2x6x6 1/2 | 266.7x152.4x165.1 | SM | 9.60 | 1240 | 1105 | 1100 | 995 | 955 |
| 9 | 12x4 1/2x8 | 304.8x114.3x203.2 | SM | 8.60 | 970 | 865 | 860 | 780 | 745 |
| 10 | 13 1/2x5 1/2x8 | 342.9x139.7x203.2 | SM | 13.00 | 1400 | 1245 | 1235 | 1125 | 1075 |
| 11 | 14x4 1/2x8 | 355.6x114.3x203.2 | SM/TR | 12.20 | 1085 | 965 | 960 | 870 | 835 |
| 12 | 15x5x11 1/4 | 381x127x285.8 | SM | 12.60 | 1290 | 1150 | 1145 | 1040 | 995 |
| 13 | 15 1/2x5x10 | 393.7x127x254 | SM | 14.00 | 1365 | 1215 | 1210 | 1100 | 1050 |
| 14 | 15 1/2x6x10 | 393.7x152.4x254 | SM | 16.80 | 1735 | 1545 | 1535 | 1395 | 1335 |
| 15 | 16×5×10 1/2 | 406.4×127×266.7 | SM | 16 | 1400 | 1245 | 1240 | 1125 | 1075 |
| 16 | 16×6×10 1/2 | 406.4×152.4×266.7 | SM | 19.27 | 1775 | 1580 | 1570 | 1430 | 1365 |
| 17 | 16×7×101/2 | 406.4×178.8×266.7 | SM | 21.1 | 2155 | 1915 | 1905 | 1730 | 1655 |
| 18 | 16 1/4x5x11 1/4 | 412.8x127x285.8 | SM/TR | 14.60 | 1415 | 1260 | 1250 | 1135 | 1090 |
| 19 | 16 1/4x6x11 1/4 | 412.8x152.4x285.8 | SM/TR | 17.60 | 1780 | 1585 | 1575 | 1480 | 1370 |
| 20 | 16 1/4x7x11 1/4 | 412.8x177.8x285.8 | SM | 20.00 | 2150 | 1915 | 1900 | 1730 | 1655 |
| 21 | 17x5x12 1/8 | 431.8x127x308 | SM | 16.00 | 1460 | 1300 | 1295 | 1175 | 1125 |
| 22 | 18x5x12 1/8 | 457.2x127x308 | SM/TR | 18.00 | 1525 | 1355 | 1350 | 1225 | 1175 |
| 23 | 18×6×12 1/8 | 457×152×308 | SM | 23.5 | 1945 | 1735 | 1720 | 1565 | 1500 |
| 24 | 18×7×12 1/8 | 457×178×308 | SM | 28.03 | 2370 | 2110 | 2095 | 1905 | 1820 |
Pneumatic solid tyre for forklift:
16x5 ,4.00-8, 5.00-8, 6.00-9, 6.50-10, 250-15, 300-15, 7.00-9, 7.00-12, 7.00-15, 7.50-15, 7.50-16, 7.50-20, 8.00-16, 8.15-15, 8.25-12, 8.25-15, 8.25-20, 9.00-10, 9.00-16, 9.00-20, 10.00-20, 11.00-20, 12.00-20, 12.00-24, 14.00-20, 14.00-24,15x4 1/2-8, 16x6-8, 18x7-8, 18x9-8, 21x8-9, 23x9-10, 27x10-12, 28x12.5-15, 32x12.1-15, 200/50-10,250-15,300-15, 355/65-15, 31x5x7, 33x6x8, 22x7x17 3/4, 385/65-24, 15-20, 17.50-25, 18.00-25, 21.00-25, 23.50-25, 26.50-25
