Linear Actuator With 12v/24v/36v/48v Voltage Limited Switch One-year Warranty for Electric Automatic Equipment

Wenzhou Huifeng Electric Co., Ltd.
Linear Actuator With 12v/24v/36v/48v Voltage Limited Switch One-year Warranty for Electric Automatic Equipment thumbnail-1
Linear Actuator With 12v/24v/36v/48v Voltage Limited Switch One-year Warranty for Electric Automatic Equipment thumbnail-2
Linear Actuator With 12v/24v/36v/48v Voltage Limited Switch One-year Warranty for Electric Automatic Equipment photo-1
Linear Actuator With 12v/24v/36v/48v Voltage Limited Switch One-year Warranty for Electric Automatic Equipment photo-2
US$ 20 - 30 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
huifeng
Model Number:
HF-TGA-A-DW
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name huifeng
Model Number HF-TGA-A-DW
Usage Boat, Car, Electric Bicycle, Fan, Home Appliance, Other, Boat, Car, Electric Bicycle, Fan, Home Appliance, skylight
Certification CCC, CE, ROHS
Type Gear Motor
Torque Requests
Construction Permanent Magnet
Commutation Brush
Protect Feature Waterproof
Speed(RPM) 4500
Continuous Current(A) 0.8(A)
Output Power 20W
Voltage(V) 12V/24V/36V/48V
Efficiency IE 3
Product Description

Product Application

Small motor actuator with ACME screws, built-in Micro switch and an internal diode, can automatically stop and enables the change of direction by simply reversing the applied voltage polarity. Stroke length can be customized. Switches are not made to be adjustable. Inversely proportional to the speed and power. Position feedback is possible.

SPECIFICATIONS FOR LINEAR ACTUATOR


Stroke
50mm、100mm、150mm、200mm......
Retracted length
190mm、240mm、290mm、340mm......
extended length
240mm、340mm、440mm、540mm......


HF-TGA-A-DW

 Speed
4mm、7mm、10mm、13mm、16mm......
Input voltage
12V、24V、36V、48V
Load
200N、400N、600N、800N、1000N......


Max static load
3000N
IP grade
 IP 65
Duty cycle
20%

Main Features

1) Simple structure in linear type ,easy in installation

2) Adopting advanced components in electric and machanical parts.

3) Limit switch to control the opening and closing.

4) Running in a high automatization and intellectualization,no pollution

5) Wireless or hand control is available

Certifications
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing
Packaging
carton box
Packaging
 wooden box
