IP65 4G LTE Rugged barcode scanner Android data concentrator
| Industrial Data Terminal S95 | |||
Performance Characteristics | Operating System | Android 4.3, supports multi- language | |
| CPU | Qualcomm Quad-Core 1.2GHz | ||
| Display | 4.0 inch WVGA (800x480), TFT-LCD | ||
| Panel | Capacitive touch screen | ||
| RAM | 1GB | ||
| ROM | 8GB | ||
| Extended Memory | Micro SD slot, up to 32 GB | ||
| Physical Characteristics | Dimensions (LxWxD) | 155 mm x 70 mm x 24 mm | |
| Weight | 280g | ||
| Keyboard | 1. Number/Alphabetic keys (including SCAN, 1aA, Backspace, Enter and Fn), LED backlight 2. Side SCAN*2 and TALK keypad*1 | ||
| Input | Chinese/ English, and supports handwriting and soft keyboard | ||
| Promting Mode | Green, red and blue LED, vibration, speaker | ||
| Barcode Scanner | 1D Linear Scanner | Code 39; Codabar; Code 128; Discrete 2 of 5; IATA 2 of&nb sp;5; Interleaved 2 of 5; Code 93; UPC A; UPC E0; EAN 8; EAN 13; MSI; EAN 128; UPC E1; Trioptic Code 39; Bookland EAN; Coupon Code; RSS-Limited; RSS-14; RSS-Expanded | |
| 2D Imager Scanner (Optional) | 1D Symbologies: UPC/EAN, Bookland EAN, UCC Coupon Code, ESSN EAN, CODE 39, CODE 128, GS1128, ISBT 128, Trioptic Code 39, CODABAR, MSI, Interleaved 2/5, Discrete 2/5, Chinese2/5 , Korean3/5, Matrix 2/5, CODE 32,CODE 93, CODE 11, Inverse 1D, GS1 DataBar, Composite Codes2D Symbologies: PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse, MaxiCode, QR Code, Aztec, Aztec InversePostal Codes: U.S. Postnet, U.S. Planet, U.K. Postal,&n bsp; Japan Postal, Australian Postal, Netherlands KIX Code, USPS 4CB/One Code/Intelligent Mail,UPU FICS Postal | ||
Radio Communication | WiFi | 802.11 b/g/n wireless communication,up to 65 Mbps, supports seamless roaming | |
| Bluetooth | Bluetooth 4.0 | ||
| WCDMA | Frequency Range: GSM:850/900/1800/1900 MHz UMTS/HSPA +: 850/900/1900/2100 MHz HSDPA Cat.8 / HSUPA Cat.6 : DL 7.2 Mbps, UL 5.7 Mbps EDGE Class 12 : DL 237 kbps, UL: 237 kbps GPRS Class 12 : DL 85.6 kbps, UL: 85.6 kbps | ||
| Adapter | 5.5V/2.6A | ||
| Options | Camera | 5.0 mega pixels with flash and automatic focus; Supports v ideo recording | |
| GPS | GPS,Supports A-GPS | ||
| RFID | Supports 13.56Mhz, ISO14443A/B and ISO15693 standard, Mifare, Felica | ||
| Sensor | Supports distance sensor, light sensor and acceleration sensor | ||
| NFC | Supports NFC | ||
User Environment | Operating Temp | -10℃ ~ 50℃ | |
| Storage Temp | -20℃ ~ 70℃ | ||
| Humidity | 5% ~ 95% (non condensing) | ||
| Sealing | IP65 | ||
| Drop Grade | 5ft/1.5m | ||
| Roller Drop Test | 500 times (1000 hits) | ||
Peripherals Accessories | Expansion | Micro SD/TF *1 (a maximum of 32 GB), SIM*1, SAM*1 | |
| Interfaces | Mini USB*1, POGO PIN*1, 3.5mm Audio Jack*1 Single slot dock(Optional) Supports to charge one unit of device and one spare battery&nbs p;simultaneously, | ||
| Single slot dock (Optional) | Input:AC 100V~240V,1A Max,50/60Hz Output:DC 5.5V,2.6A Two indicator Led:Power and Status | ||
| Regulatory | Certification | CCC, CE,ROHS,FCC | |
| Warranty | 1 year factory warranty for main device; 6 months for  ;accessories | ||
NFC
waterproof
dustproof
outdoors
Commercial Cooperation:
Our partners in more than 100 countries and regions around the world.
Our service:
1. OEM/ODM service.
2. Software customization according to customers’ requirement.
3. One year warranty for main device as well as 7*24 Online or phone technical support service.
4. Consulting Services help clients evaluate hardware, software and integrated services.
5. Onsite technical support service if online and phone services are not accessible.
FAQ:
Q The device won’t turn on.
A First please check if battery is installed correctly and battery rear cover is covered.
If there is battery and battery is installed correctly ,The program may be damaged. Please try resetting your device.
If it still doesn’t work, Please contact the service center.
Q The devicecan’t be charged.
A AMake sure the power cable and your device have been properly
connected.
Try to clean the charging terminals. If they still do not work,
your battery life might be finished or it may be a broken battery.
(The battery warranty lasts for 6 months)
Q How do I get the repair service?
A You can send the device via a delivery service to our headquarter after confirmation.
When sending the package, make sure you pay for the shipping
fee in advance.When the repair is finished, headquarter will cover the shipping cost.
Q My battery drains very quickly.
A The battery can be drained quickly when the Wi-Fi or Bluetooth is
turned on.If it drains quickly regardless of using the options above,
please purchase another battery.
Q The device won’t connect GPRS?
A First check if SIM card is installed correctly and wireless function is opened.
Then make sure the access point is set correctly and SIM card has enough fee.
If it still doesn’t work , then check SIM card is damaged or not.
| |||||
| WINCE UHF | WINCE PDA | android PDA | Rugged smartphone | Rugged UHF(ce or android) | android UHF |
| |||||
| android UHF with keyboard | Fingerprint Tablet PC | 8”android windows Tablet PC | 10”android windows Tablet PC | android Attendance machine | Thermal printer |
Contact us:
Shenzhen Wepoy Technology Co.,Ltd
Tel: +86 755-2363918 Fax: +86 755-2363919
Mob: +86 13682555556 What's App: +86 13682555556
Skype: tinaqyl Website:
