GM1605 skid steer loader with hydraulic cylinder
- 100 Unit / Units per Month
- shanghai qingdao tianjin
- T/T L/C D/P D/A Credit Card PayPal
- WECAN skid steer loader with 4 in 1 bucket, GM1605
- wecan 1.6T GM1605a mini skid steer loader for sale
- Wecan/QINGONG GM1605 skid steer loader
- SKID STEER LOADER 1600KG with china golden supplier
- Pop diesel powered Mini wheeled loader on sale! Mini skid steer loader.
- Pop diesel powered Mini wheeled loader on sale! Mini skid steer loader.
Product Details
Condition: | New | Brand Name: | WECAN | Model Number: | GM1605 |
Place of Origin: | Shandong, China | Type: | Skid Steer Loader | Moving Type: | Wheel Loader |
Dimension(Long * Breadth * High): | 3666*1980*2080MM | Rated Load: | 1605kgs | Certification: | CE, ISO |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
Main machine nude, attached parts and tools into standard export case
Product Description
GM1605 skid steer loader with hydraulic cylinder
Specifications
Item | Parameter | NO. | Major | Parameter |
Engine Model | 1104D-44T | A | Overall Operating Height (mm) | 4234 |
Bore *Stroke (mm) | 105*127 | B | Height to Bucket Hinge Pin (mm) | 3295 |
Rated Power (KW) | 74.5 | C | Height to Top of Cab (mm) | 2080 |
Rotating Speed (rpm) | 2200 | D | Height to Bottom of Level Bucket (mm) | 3100 |
Number of Cylinder | 4 | D | Overall Length without Bucket (mm) | 2878 |
Max. Torque (n.m) | 392 | F | Overall Length with Bucket (mm) | 3666 |
Displacement (L) | 4.4 | G | Dumping Angle at Maxium Height (°) | 42 |
EPA | III | H | Dumping Height (mm) | 2540 |
Max. Speed (km/h) | 10.2/20.4 | I | Dumping Reach (mm) | 850 |
Vacuum tire | 12-16.5 | G | Rollback of Bucket on Ground (°) | 27 |
Operating Load (kg) | 1600 | K | Rollback of Bucket at Full Height (°) | 96 |
Max. Loading (kg) | 3200 | L | Wheelbase (mm) | 1218 |
Lifting | Vertical | M | Ground Clearance (mm) | 218 |
Bucket Lifting Force (KN) | 2500 | N | Angle of Depature (°) | 26 |
Arm Lifting Force (KN) | 2900 | O | Turning Radius Front Without Bucket (mm) | 1540 |
Total Cycling Time (s) | ≤11.2 | P | Front Turning Radius (mm) | 2200 |
Bucket Capacity (m³) | 0.55 | Q | Rear Turning Radius (mm) | 1710 |
Pressure of Working System (bar) | 210 | S | Tread Width, Centerline to Centerline | 1530 |
Rated Flux (L/min) | 88 | T | Width (mm) | 1864 |
High Flow Flux (L/min) | 158 | U | Bucket Width (mm) | 1980 |
Fuel Tank Capacity (L) | 82 | Packing Type: | No Package | |
Self-weight witn Bucket (kg) | 4260 | Packing Details: | 2pcs/20CTN, 4pcs/40CTN |
Description | Optional Item |
1.EURO III UK ENGINE 1104D-44T 74KW 2.REXROTH PUMP 3.REXROTH DOUBLE SPEED MOTOR WITH PARKING BRAKE 4.REXROTH CONTROL VALVE WITH SAFTY LOCK 5.REXROTH HYDRAULIC JOYSTICK 6.AMERICA ELECTROMAGNETIC VALVE 7.AMERICA HYDRAULIC BALANCE VALVE 8.AMERICA BEARING 9.AMERICA 3 STAGE AIR FILTER 10.CLOSED CAB WITH HEATER,FAN,MIRROR & WARNING LIGHT 11.REVERSE BUZZER 12.TUBELESS TIRE 12-16.5 13.OUT CAB MIRROR 14.SPECIAL BIG ALUMINIUM RADIATOR | 1. AIR CONDITIONER(ONLY COOL) 2. SOLID TIRE 3. NO OUT CAB MIRROR 4. TURNING LIGHT
|
4 in 1 Bucket
Main features:
• Utility, construction and compact tractor
• Functions as a loaders bucket, clam, grapple, dozer, box scraper and bottom dump bucket
• Strong hinges and pins to distribute load
• 100,000 yield light weight material contstruction allows more load capacity
• Optional bolt-on tooth bar available
Specifications:
MODEL | 010460 | 010466 | 010472 |
WIDTH A (mm) | 1584 | 1736 | 1889 |
LENGTH B(mm) | 768 | 768 | 768 |
LENGTH C(mm) | 879 | 879 | 879 |
OPENING RANGE D(mm) | 718 | 718 | 718 |
PRESSURE OF WORKING SYSTERM (MPA) | 20 | 20 | 20 |
CLAMP FORCE (N) | 8230 | 8230 | 8230 |
OPERATING WEIGHT (Kg) | 385 | 420 | 460 |
CAPACITY (m3) | 0.4 | 0.44 | 0.48 |
