SANY 25 ton vibrating microneedle roller SSR260C

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 50 Set / Sets per Month
Port Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Single Drum Roller
Static Linear Pressure	40~70kN	Travel Speed	0-10KM/H
Grade Ability	30%	Place of Origin	Jiangsu, China
Brand Name	SANY	Model Number	SSR260C
Power(W)	119kw	Dimension(LWH)	501018802570
Weight	26ton	Certification	ISO
After-sales Service Provided	Overseas service center available

Product Description

SANY 25 ton vibrating microneedle roller SSR260C

Sany SSR260C-6 road roller useing water wheel type lubrication on the vibratory bearing extends the bearing life up to 5,000 hours. The hydraulic system of the 260hp road roller contains three stage filtration.

Higher Compaction Efficiency

10% greater excitation force than other products in the same category resulting in 16.7% greater production.

Safety First Design

Rounded bumpers front and rear

Large rear glass and sloped hood for greater visibility

Comfortable Operation

Cab mounted on vibration damping mounts

Cab climate control

Operator control forces have been reduced

Operating weight

26000kg

Weight at drum

17000kg

Weight at rear axle

9000kg

Drum static linear load

783N/cm

Compaction mechanism

Vibration frequency

27/31Hz

Nominal amplitude

2.05/1.03mm

Excitation force

416/275kN

Drum diameter

1700 mm

Drum width

2170 mm

Drum edge thickness

40 mm

Maneuverability

Travel speed - high

0-8/0-11

Travel speed- low

0-6/0-7.5

Theoretical gradeability - vibratory

43%

Theoretical gradeability - non-vibratory

45%

Ground clearance

495 mm

Wheelbase

3261 mm

Steering angle

±35°

Swing angle

±12°

Min. turning outside diameter

12800 mm

Tires

23.5-25-16PR

Engine

Model

SANY D07S3T3

Emissions

Tier III

Rated power

180KW

Capacity

Battery

24x100 VxAh

Fuel tank

300L

Hydraulic oil tank

200L
