Home > Products > Electric /Battery Forklift Truck > 1.5Ton Electric Forklift Truck
1.5Ton Electric Forklift Truck
Negotiable
/ Set
1 Set(Min.Order)
- 1000 Set / Sets per Month
- Shanghai
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Shanghai, China | |
| Brand Name | GP | Model Number | CPD15 | |
| Type | Powered Pallet Truck | Power Souce | DC Motor | |
| Rated Loading Capacity | 1500kg | Max. Lifting Height | 6500mm | |
| Min. Lifting Height | 3000mm | Fork Length | 920mm | |
| Fork Width | 100mm | Overall Dimensions | 2056*1090*2162mm | |
| Certification | ISO&CE | After-sales Service Provided | Overseas service center available |
Product Description
Specifications
1)Small size for factory or warehouse2)Silent type motor
3)GE traveling electronic controller
4).5-7 hours working times
GE traveling electronic controller Advanced transverse transmission system Reliable separately excited motor
model | CPD10 | CPD15 | CPD20 | CPD25 | CPD30 | |
load capacity | kg | 1000 | 1500 | 2000 | 2500 | 3000 |
load center | mm | 500 | ||||
weight with load | kg | 2995/745 | 3880/560 | 4940/1040 | 5760/860 | 6830/1020 |
weight without load | kg | 1250/1490 | 1290/1650 | 1740/2240 | 1760/2360 | 2085/2764 |
drive speed | km/h | 12/13.5 | 11.5/13 | 12.5/14 | 12/13.5 | 14.5/12 |
turning radius | mm | 1930 | 2320 | 230 | ||
Min.barcket routeway | mm | 2000 | 2400 | 2280 | ||
towing force | kn | 5.5 | 7 | 10 | ||
gradeability | % | 15 | 10 | 10 | ||
lifting speed | mm/s | 235/320 | 230/320 | 272/430 | 260/480 | 280/420 |
lowering speed | mm/s | 600 | ||||
overhead guard height | mm | 2100 | 2170 | 2125 | ||
mast height | mm | 2015 | 2070 | 2040 | ||
complete size | mm | 1985*1070*2100 | 2325*1170*2170 | 2481*1265*2125 | ||
free-lift height | mm | 130 | 135 | 140 | 145 | 145 |
chair with guard height | mm | 1000 | 1015 | 1020 | ||
lifting height | mm | 3975 | 4030 | 4270 | ||
fork size | mm | 920*100*30 | 920*100*35 | 1070*120*40 | 1070*120*42 | 1070*125*45 |
wheel distance | mm | 900/930 | 980/954 | 1040/980 | ||
hold under mast | mm | 99 | 105 | |||
work pressure | mpa | 14.5 | 17.5 | 18.5 | ||
battery voltage | V | 48 | 50 | |||
battery capacity | Ah | 400 | 450 | 620 | 700 | 500 |
travel motor power | Kw | 5 | 8 | 13 | ||
subsidiary motor power | Kw | 7.5 | 8.6 | 10 | 22 | |
gear type | CBTD-F412.5 | CBTD-F423 | CBTD-F430 | |||
