100m3 Gold Mining Washing Plant

FOB Price

USD $50,000 - $80,000 / Set

1 Set(Min.Order)

Supply Ability 10 Set / Sets per Month
Port Qingdao
Payment Terms:T/T D/P D/A Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Condition:	New	Type:	Gravity Separator	Production Capacity:	98%
Place of Origin:	Shandong, China	Brand Name:	SG	Model Number:	SG-GM100
Voltage:	Clients Local Standard	Power(W):	30KW	Dimension(LWH):	11.92.32.9m
Weight:	13T	Certification:	ISO9001	Warranty:	1 Year
After-sales Service Provided:	Engineers available to service machinery overseas

Packaging Details

Nude packing. 1*40'gp

Product Description

100m3 Gold Mining Washing Plant

1.Features:

- High Quality Placer Gold Mining Trommel Screen ;

- This gold mining plant can improve the recovery of the gold and reduce the workload of cleaning.;

- get gold with little impurity;

- Can do continuous process, advanced spiral system, increase gold recovery rate, reduce operator;

2. High Quality Placer Gold Mining Trommel Screen Specification:

NO	Item		Remark
1	Dimension
	Length	11.9m
	Width	2.3m
	Height	2.9m
	Operating Weight	13000kg
2	Wet-type hopper	LW: 3.7m2.4m
3	Trommel with washing function	Φ0.9m,L: 7.5m	With two washing room
	Sieve pore	6mm,8mm	Optional
4	Outside Drums	Φ1.8m,L: 6m	1/This section is the drum outside the trammel. 2/The section with screw is used for separating the gold from the sand
	Speed governing method	Frequency converting control	This function can make the plant run at a low rate with efficiency such as 20tph for example.
5	Concentrate Sluice	LW: 6m0.3m
	Efficient mats	2sets*
6	Tailings Sluice	LW: 6m1m
	Efficient mats	2sets
7	Conveyer belt	Belt LW: 9m0.6m
7	Diesel water pump	DP6"
	Flux/Pumping head	200m³/30m
8	Generator set	Weichai 30kw
	Diesel driving motor	4100ZLD
9	Handling capacity	100m³/h
10	Feed way	Excavator or wheel loader
11	Loading	1*40HQ

Packaging & Shipping

All the high quality placer gold mining trommel screen packed in nude. We can also provide many types of packaging to meet any special requirements.

Model	Diamension	Quantity
SG-GM10	4.72.32.9m	1*20'GP
SG-GM100	11.92.32.9m	1840'GP

Working site:

Our Services

Customer’s requirement is our first priority. We can provide reliable, fast and professional 24/7 service for you through telephone, on-site or network channels.

Regarding the warranty time, 12months, during the Guaranteed Period, service of guarantee will be supplied on condition that the machine or parts appear to have defects because of bad quality.

Regarding spare parts,we have enough ready stock for supply to our customers, which can guarantee to help them get parts and replace them on machines in shortest time.

Regarding technical support, we have professional engineer and technician to answer your question and doubt for machines and any problem you have during operation with machines.

Regarding logistic and shipping, we have long-term and trustworthy forwarder to supply you one-stop service.

SincerelyLooking forward to cooperate with you!

Contact: Frank

Phone No.: 86-15265755218

Skype: Frankyang23
