With CE compact stracture road roller,3 ton with cab double drum vibratory road roller

Specifications

1.Hydraulic front wheel vibrate
2.With articulated steering
3.Compact integral structure
4.Easy to operate
5.CE certificate

With CE compact stracture road roller,3 ton with cab double drum vibratory road roller





1----Basic configuration/   QLNC3B

1.Mechanical rear wheel drive, Hydraulic front wheel vibrate,articulated steering;

2.Adopt hydraulic help in the brake shoes;

3.Engine: adopt changchai 385 engine;

4.Have sunshade shelter.



2---- Features /    QLNC3B

1.Mechanical movement, hydraulic vibration, hydraulic rotation, with reliable performance and optimum function/price ration

2.Both front and rear wheels have scraping and water spray unit.

3.Adope N385Q series diesel engine,very convenient for use and maintenance.

4.Compact integral structure,small volume,capable of used for compaction on narrow site.



3---- Main Technical Parameters/   QLNC3B

MODEL		QLNC3B
Operating mass	kg	3000
Static linear load	N/cm	128/172
Vibration frequency	Hz	50
Centrifugal force	kN	30
Travel speed	km/h	5.6
Grade ability	%	20
Turning speed	mm	5000
Overall dimension	mm	2900x1314x2600
Drum width	mm	1000
Wheelbase	mm	2100
Diesel power	kw	21
Diesel model		ZN385Q



4. Range of application/    QLNC3B



LTC series wheeled vibratory roller is applicable for maintenance of municipal roads and highways,

as well as the compaction of the narrow road surfaces such as groove foundation with width above 1.1m,

building construction, pipeline backfill and stadium.



5. Pictures display/   QLNC3B

General view



Details

 Certificates
