portable welding generator set (KDE6500EW)
- 54000 Piece / Pieces per Month
- Shanghai
- T/T Credit Card
Product Details
| Place of Origin: | Jiangsu, China | Brand Name: | SUMOKAMA | Model Number: | portable welding generator (KDE6500EW) |
| Output Type: | AC Single Phase | Speed: | 3000 3600 | Frequency: | 50 60 |
| Rated Power: | 6.2/3000 6.5/3600 | Rated Voltage: | 230 240 | Rated Current: | 8.7 9.2 |
Product Description
Specifications
portable welding generator set (KDE6500EW)1. Japan technology
2. CE/ISO9001 passed
3. More color optional
Product Description
1. CE approved, powered by sumokama advanced air-cooled diesel engine.
2. Electric start system ensures rapid start of the set.
3. Large fuel tank, ensuring hours of continuous output.
4. Low oil pressure alarm system, which can shut down the engine automatically.
5. Integrated cabinet ensures the set running silently.
6. A variety of specially-designed control panels available for different markets.
Model | YM7500EW | |
Frequency (HZ) | 50 | 60 |
Rated Output (KVA) | 2.0 | 2.2 |
Rated Voltage (V) | 230 | 240 |
Rated current (A) | 8.7 | 9.2 |
Rated rotation speed (rpm) | 3000 | 3600 |
No-load welding voltage V | 65-67 | |
Rated welding voltage V | 26-30 | |
Rated welding DC: A | 160 | |
Current adjusting extension | 50-190 | |
Welding Electrode φ (mm) | 1.6-4.0 | |
Welding load continuous ratio | 50% | |
Phase No. | Single phase | |
Power Factor | 1 | |
Excitation Mode | Self-excitation, 2 pole and constant voltage (AVR) | |
DC Output | 12V. /8.3A , Connection Pole Output | |
Structure Type | Open frame type | |
Noise Level (7m) dB(A) | 85 | |
Engine Model | YM186FA | |
Engine type | Single-Cylinder, Vertical, Four-Stroke, Direct Injection, Air Cooled Diesel | |
Bore × Stroke(mm) | 86× 72 | |
Displacement (L) | 0.418 | |
Rated Power KW | 6.2/3000 | 6.5/3600 |
Fuel comsumption Rate(g. kw/h) | 275.1 | 281.5 |
Compression Ratio | 19: 1 | |
Lubrication System | Pressure Splashed | |
Starting System | Electric Start with 30Ah MF battery | |
Fuel Type | 0#(summer), -10#(winter), diesel | |
Lube Oil Brand | SAE10W30 (above CD Grade) | |
Lube Capacity (L) | 1.65 | |
Fuel Tank Capacity (L) | 12.5 | |
Continuous Running Time (hr) | 12 | |
Overall Dimension: LxWxH (mm) | 750 x 520 x 660 | |
Dry Weight (Kg) | 110 | |
Quantity in 20FT | 99 Pcs | |
We reserve the right to change specifications without notice | ||
