2KW single phase small portable electric air-cooled super silent with ATS diesel generation

FOB Price

USD $300 - $320 / Piece

10 Pieces(Min.Order)

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

CE approval & ISO9001:2008
Portable generator
1 year warranty & spare parts
100% Copper Wire Alternator

Model	KDE2500E
Frequency (HZ)	50	60
Rated Output (KVA)	1.7	2.0
Maximum Output (KVA)	2.0	2.2
Rated Voltage (V)	115/230	120/240
Rated current (A)	14.8/7.4	16.7/8.3
Rated rotation speed (rpm)	3000	3600
Phase No.	Single phase
Power Factor	1.0
Excitation Mode	Self-excitation, 2 pole and constant voltage (AVR)
DC Output	12V. /8.3A , Terminal Post
Noise Level (7m) dB(A)	77
Engine Model	KM170FE
Engine type	Single-Cylinder, Vertical, Four-Stroke, Direct Injection, Air Cooled Diesel
Bore × Stroke(mm)	70 x 55
Displacement (L)	0.211
Rated Power KW	2.5/3000	2.8/3600
Fuel comsumption Rate(g. kw/h)	280.2	288.3
Compression Ratio	20: 1
Lubrication System	Pressure Splashed
Starting System	Electric Start with 30Ah MF battery
Fuel Type	0#(summer)-10#(winter) diesel
Lube Oil Brand	SAE10W30 (above CD Grade)
Lube Capacity (L)	0.75
Fuel Tank Capacity (L)	12.5
Continuous Running Time (hr)	20
Overall Dimension: LxWxH (mm)	660 x 500 x 570
Dry Weight (Kg)	60
Quantity in 20FT	132 Pcs
Optiomal Features: Remote, ATS(Auto Transfer Switch), Digital Panel
We reserve the right to change specifications without notice
