china 800kg wheel loader, small wheel loader with snow blade
- 100 Set / Sets per Month
- QINGDAO CHINA
- T/T
- China 2 ton mini loader, JT920 wheel loader with timber grapple
- Mini Compact Wheel Loader 1000kg wheel loader For Sale
- China used wheel loader 936 Wheel loader with good condition
- China 1.6Ton ZL16F wheel loader with CE Certified Europe Market, with forks
- Latest export ZL20F 2.0 TON 1.0-1.3CBM wheel loader with bottom fork
- Latest export model ZL08/ZL08F/ZL08B 0.8 ton mini wheel loader
Product Details
Condition: | New | Brand Name: | JINTAI | Model Number: | ZL08B |
Place of Origin: | Shandong, China | Type: | Front Loader | Moving Type: | Wheel Loader |
Dimension(Long * Breadth * High): | 4700x1600X2350 | Rated Load: | 800 | Certification: | ce |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Model | Mini Wheel Loader ZL08F |
Rated Loading Weight | 800kg |
Rated Bucket Capacity | 0.4m3 |
Bucket type | Heavy-duty bolt on teeth |
Max. Breakout Force | 28KN |
Operating Weight | 2350kg |
Engine | |
Engine Model | ChangChai L24 |
Engine type | In-line arrangement, water cooled, one cycle |
Rated Power | 17KW(23.12H.P.) |
Rated Speed | 2200 r/min(rpm) |
Fuel Consumption | 269g/kw.h |
Steering System | |
Cycloid full hydraulic steering system | BZZ-80 |
System Pressure | 10MPa |
Operating Specifications | |
Drive Type | Four-wheel drive |
Min Turning Radius | 4600mm |
Driving System | mechanical |
Dumping Height | 2300mm |
Dumping Reach at max height | 750mm |
Min Base to the ground | 240mm |
Time of raise | 4sec. |
Hydraulic cycle time | 9sec. |
Brake System | |
Service Brake | Four Wheel Hydraulic spread-shoed brake |
Parking Brake | Hand operated |
Tire | (1) Model 8.25-16 (2) Width: 20cm (3)Diameter: 80cm |
Overall Dimensions( L x W x H) | 4700x1600x2350mm |
Wheelbase | 2170mm |
Track | 1285mm |
Features and Performance of wheel loader in LaiGong
1 Easy to own
Low cost of ownership represents overall value for money. High bucket break out force results in increased productivity. Tried and tested components from Cummins, Kawasaki and ZF deliver reliable performance.
2 Easy to operate
Spacious and ergonomically designed cab ensures excellent operator comfort during long working hours 360 degree clear visibility, which is supported by a rear view camera, provides enhanced health and safety on busy job sites. Boom kick-out and return-to-carry feature ensures efficient loading.
3 Easy to maintain
Rugged construction and reinforced parts result in less damage and machine downtime. Easy maintenance access and dedicated European dealer support network ensure maximum uptime Powerful Stage IIIA and Stage IIIB-compliant engines deliver excellent fuel efficiency.
1.After computer optimization design, it features high-position leveling function and substantially higher operation efficiency.
2.Designed and produced by the company, transmission features robustness and durability, rational matching of transmission ratios at different gears and reduction of power consumption.
3.Load-sensing full hydraulic preferential steering, featuring stability, reliability and substantial energy-saving.
4. Pin of bucket loader features dust-proof rubber seal, and extension of usage life of pin and sleeve.
1.Reply your inquiry in 24 working hours.
2.Experienced staffs answer all your questions in professional and fluent English.
3.Customized design is available. OEM is welcome.
4.Exclusive and unique solution can be provided to our customer by well-trained and professional engineers and staffs.
5.Special discount and protection of sales area provided to your distributor.
6.Do the best reliable heavy-duty single drum vibratory road roller in China.
7.Warranty period is 1-year or 1500 working hours against Bill of Lading.
Company and Products Information Related
Why choose us?
1) CE,BV,SGS,ROPS and FOPS verified.
2) We are a wheel loader manufacturer with 10-year experience.
3) Customers-focused,anytime,any question we will reply you ASAP.
4) All wheel loaders have best premium quality and reasonable price.
5) Providing a one year warranty for after-sales service.
6) Easy-demaged components are not included in warranty.
7) Delivery term:within 15 days after down payment. An 8)integrated customer follow-up system had been built that helping us to provide premium after-sales service,saving your precious time.
