Container semi trailer truck carrier

FOB Price

USD $10,000 - $30,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Container semi trailer truck carrier semi truck
1,low transportation cost
2,high conveying efficiency
3,low fuel consumption

Container semi trailer truck carrier semi truck

Container semi-trailer truck specification:

Vehicle model	CLW9280TJZG Container semi-trailer	Batch No.	229
Manufacturer	Hubei Chengli Special automobile Co. ,Ltd(china)	Brand name	CLW
Overall dimension(mm)	7500×2500×1510	Total weight(Kg)	27750
Body internal dimension(mm)	××	Rating load(Kg)	24000
Approach/departure angle	-/26	Curb weight(Kg)	3750
Front/rear hang(mm)	-/1100	Max speed(km/h)
Axle number	2	Tyre number	8
Wheelbase	4240+1300	Tyre specification	11.00-20 12PR,11.00-20 14PR,11.00-20 16PR,11.00R20 12PR,11.00R20 14PR
Axle load	-/17990(double axles)	Front wheel distance
Leaf spring number	-/8/8	Rear wheel distance	1840/1840
Remarks	Container semitrailer tractor the saddle bearing surface-load from high to 1310mm, traction pin at the frame height 85mm;Car used to transport the 20-foot container.
Others	Protectivematerial:Q235 carbon steel. Connection: around the side and rear underrun protection are welded connection, rear protective section size (mm): 200 × 50 × 5.the rear protective ground clearance (mm): 520. ABS manufacturers:Haldex International Trading (Shanghai) Co., Ltd., ABS Model:2S/2M.
