Dongfeng dlk one tow two flatbed tow trucks

Main specification

Product model and name

CLW5070TQZP3 flatbed tow trucks

Gross weight(Kg)

7490

Drive type

4X2

Curb weight(Kg)

5495

Overall dimension(mm)

7420X2300X2540

Approach/departure angle(°)

20/10

Cab seats

3

Axle No.

2

Front/rear hang(mm)

1180/2440

Axle load(Kg)

3150/4340

Wheelbase(mm)

3800

Max speed(Km/h)

90

Chassis specification

Chassis model

EQ1070TJ9AD3

Manufacturer

Dongfeng Motor Co., Ltd

Brand name

Dongfeng DLK

Dimension(mm)

6695×2285×2350

Tyre specification

7.50R16

Tyre No.

6

Steel spring number

11/9+7,8/10+7

Front track base(mm)

1835,1750

Fuel type

Diesel

Rear track base(mm)

1640,1586

Emission standard

Euro 3

Transmission

5 forward gear, 1reverse gear

Cab

Luxurious interior trim with dashboard and air condition.

Engine model

Engine manufacturer

Displacement(ml)

Power(Kw)

CY4102-E3C

Dongfeng Chaoyang Chaochai Power Co.,Ltd

3856

91(125HP)

Performance

Flat length(mm)

5600

Flat width(mm)

2300

Max pulling weight(Kg)

4000

Max lift weight(Kg)

3000

Vehicle accessories

Training wheels, Steel wire rope, bandage, Alarm lamp, Tyre Covers,Jack, spare tyre ,drivers’ tools

1.About the package of our trucks,usually it is nude that covered with wax.And it also can be packed as your need.

2.About the shipping,there are many ways,such as Ro-Ro Ship / Bulk transport / Container packing / SKD / etc. And it can be offered according to your request.
