30KN Hydraulic Fiber Optic Cable Tensioner during transmission line
USD $18,000 - $19,200
/ Set
1 Set(Min.Order)
- 10 Set / Sets per Month
- SHANGHAI
- T/T
You May Like
-
2016 qualified 7 Ton Hydraulic Wire tensile machine
-
2016 Manufacturer qualified 7 Ton Hydraulic Wire tensioner machine
-
3T Transmission Line Tension Stringing Equipment
-
7.5KN ADSS OPGN Line Tension Stringing Equipment , Pressure Cable Tensioner with 4 Groove
-
7 Ton Hydraulic Wire Tension Machine Hydraulic Cable Pulling Tensioner
-
7 Ton Hydraulic Conductor Tensioner Cable Pulling Machine
Product Details
| Place of Origin | Jiangsu, China | Brand Name | XINYA | |
| Model Number | SA-YZ30A | Type | Hydraulic Pullers |
Product Description
30KN Hydraulic Fiber Optic Cable Tensioner during transmission line
Application
30KN Hydraulic Cable Tensioner adequate to tension releasing various conducts and earthwires .and also useful for tension releasing OPGW optic cable compounded earthwire and ADSS self–stand optic cable .etc .
Features
1. Bullwheel with wearproof MC nylon lining segments.
2. infinitely variable tension control and constant tension conductor stringing .
3. it adapt Italian reducer .
4. spring applied hydraulic released brake acts automatically in case of hydraulic failure to ensure safety
Main component
1. Engine :Domestic water –cooled engine .
2 .Main pump/motor ,Chinese famous branded pump and motor .
3. Reducer :RR(Italian )
4. Radiator: AKG
5. Hydraulic instrument : WIKA
6. It can choose import engine .
Technical Data
| Model Type | SA-YZ30A |
| Overall Size(MM) | 3560 *1600*2220 |
| Weight(KG) | 1700 |
| Max Tension(KN) | 30 |
| Max Continual Tension(KN) | 25 |
| Bullwheel bottom of groove diameter | Φ1200 mm |
| Diameter of Tension wheel(mm) | 1200 |
| Number of grooves | 5 |
| Maximum pullback (KN) | 20 |
| Maximum suitable conductor diameter | 32 |
| Engine power /speed (kW/rpm) | 11/2200 |
Please tell us the following information in your enquiry:
1. Max Tension(KN) ?
2. Diameter of Tension wheel(mm) ?
3. Maximum suitable conductor diameter ?
4. Quantity?
We'll give you a good price after confirming the above info.
Welcome to contact us by phone or e-mail, if you are interesting in our products.
