Home > Products > road sweeping truck > Dongfeng 4*2 sweeper truck

Dongfeng 4*2 sweeper truck

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 300 Set / Sets per Month
Port Shanghai
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Condition:	New	Transmission Type:	Manual	Emission Standard:	Euro 3
Fuel Type:	Diesel	Dimensions (L x W x H) (mm):	703024353030	Gross Vehicle Weight:	16000
Place of Origin:	Hubei, China	Brand Name:	Dongfeng	Model Number:	YSY5160TSL

Product Description

Specifications

Dongfeng 4*2 sweeper truck
1>Engine power: 210hps
2>Dirve type: 4*2
3>Emission standard: Euro 3

Product	Dongfeng 4*2 sweeper truck
Vehicle model	YSY5160TSL
Chassis model	DFL1160BX1
Chassis parameters	Overall dimensions	mm	7030×2435×3030
	Gross weight	kg	16000
	Curb weight		8880
	Suspension F/R	mm	1430/1880
	Wheel base		3800
	Drive type		4*2
	Number of axles		2
	Number of Spring leafs		7/9+6,8/10+8
	Tire specification		9.00-20,9.00R20,10.00-20,10.00R20
	Number of Tires		6
	Allowable passengers in cab		2
Engine	Engine model		ISDe210 30
	Type of fuel		Diesel
	Displacement/power	ml/hp	6700/210
	Max speed	Km/h	90
	Emission standard(TAS)		EURO 3
Other main equipments and parameters	Main equipments		Equipped with four sweep plates combined with the sucking mouth .The sweeping and sucking capacity is wonderful
			Equipped with stainless steel rubbish tank ,clean water tank and dirty water tank
	Parameters		Max cleaning width (mm)	2000
			Max cleaning capacity (m2/h)	30000
			Cleaning efficiency	90%
			Max cleaning speed (km/h)	20
			Max tipping angle (°)	≥45
			Max suction granularity (mm)	55
			Garbage tank capacity (m3)	4
			Water tank capacity (m3)	0.8

Payment terms and delivery:

Delivery date: 7-10 days

Payment terms: 30% TT as deposit and 70% TT upon receipt of B/L copy

Packing: nude, covered with wax, small type can be put into 20'GP or 40'GP, big type can be carried by bulk carriers or ro-ro ship or according to your requirements

Remarks:

The above information is just for your reference. We can manufacture the trucks as per your request and we can fulfill all your demands.

Should you have any other questions or need any other information, pls feel free to contact me. It would be my great pleasure to be on your service. Pls check my contact information as following:
