35t Flatbed Container Semi-trailer

Specifications

35t flatbed container semi-trailer

Name : 35t flatbed container semi-trailer

Overall size : 13250x2500x2680mm

Platform size: 8700x2500mm

Weight

(1) Complete vehicle Curb mass: 13000 Kgs

(2) Capacity load: 35000 Kgs

(3) Total weight: 48000 Kgs

Frame: Double main beams (Q345B/ST52-3), through cross beams (Q235) and 4mm pattern plate frame, it is high intensify. When the side fold guard open, the width will add to 3000MM

Running gear

(1) Axle: 3 units of 13 tons axles

(2) Suspension: BPW air suspension system, the first axle can be risen.

(3) Wheel rim: 9 -22.5

(4) Tire: 315/70R22.5x13 (Spare tire 1pc included)

Kingpin : 2 Bolting type

Landing gear : Double-speed linkage

Brake system : Double pipe line air brake, WABCO brake valve, 30/30air chamber.

Electrical system : 24V, seven core socket, lights accord to standard in China.

Others

(1) Spare tire bracket: 2 units, put in the front

(2) Tool box: 1 unit

(3) One set of drivers tool: 1 Tire spanner, 1 Gudgeon sleeve, 1 Cranking bar

(4) Steel side guardboard

(5) Rear hydraulic ramp ( The hydraulic pump on tractor, driven by electric connection from the tractor )

(6) The height of the fifthwheel: 1350mm

(7) The space from the front to the kingpin: 1350mm

(8) Others according to LOHR standard

Surface treatment :

(1) Shot blasting for complete semi-trailer

(2) Prime coat and final coat, color accord to the requirement of customer.

Packing: Two units one package for bulk shipping

Payment terms and delivery:

Delivery date: 7-10 days

Payment terms: 30% TT as deposit and 70% TT upon receipt of B/L copy

Packing: nude, covered with wax, small type can be put into 20'GP or 40'GP, big type can be carried by bulk carriers or ro-ro ship or according to your requirements

Remarks:

The above information is just for your reference. We can manufacture the trucks as per your request and we can fulfill all your demands.
