Help CenterDongFeng 153 Wrecker,wrecker Hydraulic,heavy Duty Rotator Wrecker
Related Products
Specifications
road wreckerDongfeng 4*2 road Wrecker
Lift Weight: 4000kg
Engine: Commins
Horsepower: 180hp
road wrecker, also called wrecker and road construction wrecker
1. Contact Information
2. Factory Certifications
Item | Unit | Parameter | |
Model |
| CLW5140TQZRoad Wrecker | |
Chassis |
| EQ1141G7DJ2 | |
Overall dimension | mm | 7840×2480×3030 | |
Fact lift weight | kg | 3800-4000 | |
Mass in working order | kg | Appro×10300 | |
Arm extension stroke of lift | mm | Approx2000 | |
Max loading weight | kg | Approx14000 | |
Max starting power | Kg | Approx13000 | |
Case dimension | mm | NO | |
Wheel base | 5000 mm | Engine type | EQB180-20 |
F/R track base | 1940/1860 mm | Exhaust/hp | 5880/132 ml/kw |
F/R over hang | 1245/1970mm | fuel consumption / 100 km | 22.4L |
Approach/Departure angle | 34/14 ° | Min turning radius | 18 m |
Max speed | 90 km/h | Max grade ability | 28° |
Tire | 10.00-20 | Min ground clearance | 248 mm |
Armor plate spring quantity | 8/10+8 | Gearbox | 6speeds |
Brake System | Exhaust brake | Clutch | 395 mm |
Brake space | 8.5m | Air condition | optional |
Traction system | 4×2 | Electric system | 24v |
Number of axles | 2 | Allowable passengers in cab | 3 |
Function brief introduction
Main features are: Equipped with hydraulic pressure system, neat-structured, flexible and reliable.
The crane, which functions with single vat, can be landed to support the truck and guarantee the trucks stability. It can be equipped with either semi-automatic or fully automatic tugboat.
The capstan can be driven either by hydraulic pressure or power supply of the truck itself. Accessories for clearing the barriers are sound-equipped to secure the efficient work. The traction supporting crane operated by the hydraulic pressure system is highly flexible.
The assistant wheel can hold the locked wheels to tract.
It is also equipped with high-latitude signal lamp. Searching lamps can also be equipped to guarantee night barrier-cleaning work.
Tools operated by high pressure for dismantling barriers can be equipped to do saving activities on spot.
