high quality big Backhoe Loader

bulk or as required

Specifications

high quality big Backhoe Loader
High qualiy with reasonable price
Excellent performance
Good after-sales service
ISO

high quality big Backhoe Loader

  Introduce:

    The XT860 Backhoe Loader is a new multi-function engineering machine which gathering the loading and excavating in the integral whole machine. It is the new generation model of the development based on the same kind product technique in domestic and international.Having adopted four wheel drive,hydraulic torque converter,hydraulic streering system,hydrulic.It is extensively used in the roadmaintenance,farml and developments,getting clay for making brickiln,piping builds,the cable builds,park virescence and the excavating of the road opens to dig,broking upetc,This machine has below characteristics;The Yucai engine:low noise,low exhaust gas,low west,green environmental protection,driving motive,good reliability The spirit valve control take type brake system and system,it can make intime brake automatically,so it is more safety,Humanization designs:the hand handle layout reasonable,manipulating is portable;steer device,gauge dish and the chair all can be adjusted in up-down and front-back directions according to your sense,so it is comfortable,The back wheel bridge can swing up and down round the cencer,it make wheels has well clinging,so the machine has good span and cross capability,optimized load work device:reasonable joint layout,dependable position linit function,lavelling bucket automatically in unload position,lacenning labor intensity,and the work range is larger,workfore is more sturdy and steady,the work efficiency is higher,special middle placed backhoe and wing-spread support leg.when the machine break up stones and do deeper dig work.it has stronger stability than other





Description	XT860 Backhoe Loader	Unit
Working weight	8400	kg
Overall dimension (L*W*H)	8100*2366*3680	MM
Max. Travel speed	21	km/h
Wheel base	2290	mm
Turning radius	5110	mm
Tires (F/R)	16/17-20
Rated pressure	18Mpa
Rated power	60kw
Rated speed	2400	r/min
Engine model	LR4105G90
Engine brand	Chinese Luotuo
Fuel consumption	224	g/kw.h
Bucket capacity	0.8-1.2	CBM
Dumping clearance	2570	mm
Dumping reach	745	mm
Digger capacity	0.2-0.25	CMB
Max. Digging depth	4290	mm
Max. Digging radium	5450	mm
Drive type	4WD
System voltage	24	mm
