Products Description:

Features
A machine is a high-speed, precision, small portable cutting machine as one of the modular structure.
Applications: sheet metal processing, electrical equipment, machinery manufacturing, machinery manufacturing, aerospace, vehicle manufacturing.

Technical advantages
1 Equipment easy to install, simple to operate, easy to use; lightweight, easy to install relocation, small sizes suitable for cutting sheet steel, capital investment is relatively small.
2 Beams using a portable aluminum structure, model molding, high stability, saving the plant area. Using longitudinal rail structure, high precision, longitudinal rails may need to lengthen.
3 The Shanghai Fang Ling 2100B5 inch color LCD, plasma interference with anti-lightning and surge capacity.
4 Chinese / English operation interface conversion, dynamic graphics, motion tracking, using U disk reader.
Cutting mode
1 is suitable for limited user space, cut a smaller format processing environment, especially for non-ferrous metals of various thickness, stainless steel, aluminum and carbon steel plate cutting stock.
2 flame cutting using oxygen gas, biogas, liquefied petroleum gas, such as acetylene;

Standard configuration
1 arm length 2200mm
2 longitudinal length of 3000mm
3 flame separatism 1
4 flame cutting cutting mode
5 Cutting gas oxygen, acetylene, methane, liquefied petroleum gas and other
6 drive system drives the original Raiser
7 control system Shanghai Fang Ling 2100B
8 nesting software programming FastKAM Standard Edition

This product is a portable CNC cutting machine can cut any complex graphics plane, support flame, plasma cutting. Reduce secondary processing, improve production efficiency.
This product is a reasonable organization, small size, light weight, can be any movement, do not account for a fixed venue, suitable for indoor and outdoor cutting.
Cutting software supports graphics, nesting. Easy to learn.
Software and nesting CAD, or computer graphics can be converted to G code graphing cut parts with the G-code file into U disk, enter the cutting machine, the system will automatically cut G code into the program.
The product is equipped with a USB interface for easy program transfer. In nesting software set kerf compensation value.

Structure Introduction
The machine includes a main body, base, beams and torch parts.

Technical Parameters:
180W rated power
Specifications 5.7-inch LCD screen
Host body size: 508x344x305
X to the effective cutting (beam) 1700mm
The actual length of 2200mm beam
Y-effective cutting (track): 2600mm
Track actual length: 3000mm
Track width: 196mm
Cutting speed: 0-2500mm / min
Cutting thickness (flame): 6-150mm
Cutting thickness (ion): 2-20mm
Beam weight: 9.3Kg
Host body weight :26.7Kg
Longitudinal rail Weight: 34.5Kg
Machine weight: 70.5Kg
Type of gas acetylene, propane, methane
